PRODUCT DESCRIPTION

7. ACCESSORIES

Accessories that are not included in the standard order must be ordered separately.
Set of compressed air outlet filters
The compressor may be equipped with a set of filters if specified. The filter set may be equipped
with an air pressure regulator.
Where a different level of air filtration is required, this requirement must be
agreed upon with the supplier and specified in the order.
Type
FS 40F
FS 40M
DK50
2x4VR/110
FS 40S
FS 40AH
*) These FS do not contain a filter bypass, which will ensure a continuous flow of air when replacing
the filter element. Such a set must be ordered separately.
Filter set regulator assembly
The compressor may be equipped with a pressure regulator of the compressed air outlet if specified.
The regulator must be selected according to the application to the filter set, or separately The
regulator shall ensure constant pressure at the outlet.
Type
Regulator complete
REG15
Filter set brackets
A suitable bracket must be ordered for every filter set.
Type
Compressor-mounted bracket
Wall-mounted bracket

8. PRODUCT FUNCTION

8.1. Compressor with adsorption dryer
The compressor aggregate (1) draws in air through the inlet filter (8) and compresses it through a
check valve (3) and into a manifold, from which it is routed to the adsorption dryer (9) through a
connecting hose. From the inlet to the dryer module, the air is first cooled in the integrated cooler
(14) and then moves through the condensate separator (40), entering the active chamber with
adsorbent (16), where the air is dried. A portion of the air is fed into the second, regeneration
chamber, where this air is used to remove moisture from the adsorbent, after which it is released
through the silencer (38). The active chamber switches on a cyclical basis. The dry and filtered air
then passes through the check valve (3) into the air tank (2).
09/2020
Level of filtration
Use
1+0.01
1+AC+HC (0.01)
DK50 2x4VR/110/M
DK50 2x4VR/110/M
(µm) function *
1
1+0.1
Use
Use
11
Bypass
Article number
604014119-000
604014119-004
no
604014119-024
604014119-005
Article number
604014125-000
447000001-243
Article number
604014131-000
603014120-000
