6| mounting variants

The unit may only be mounted on the following objects:
Wall
䕲
Door
䕲
Outdoor
䕲

7| Mounting instructions

7.1| mounting: Wall

important notes
Before installation, please check what material your desired mounting location is
䕲
made of and whether it is load bearing (concrete wall/brick wall). Cavity walls or
plasterboard walls are NOT suitable for mounting the unit (exception: stud wall with
additional plate).
Before mounting, the course of power and water lines in the wall must be checked! If
䕲
you are unsure about the course of lines in the wall, have them checked by an expert
if necessary.
Installing the wall adapter
Upper wall adapter:
Mount the upper wall adapter first so that the Super Belt can be used as a plumb bob
䕲
for the lower adapter.
When mounting the upper wall adapter, please use the following rule of
䕲
thumb to define the correct mounting height according to your height:
Lower edge of upper wall adapter at height of outstretched arm *
(see figure on the right)
Mounting only on brick or concrete walls,
mounting on stud wall only possible with additional plate!
No mounting on glass doors! Check door for stability before
mounting! The door should be solid and should have a door frame
into which it can be pulled.
Mounting on tree/post (round/onered) is possible.
No mounting on electricity pylons!
