FastBuild™ Configuration Setup
Creating A Mirrored Array Using New Drives
As described in the Drive Assignments Option section above, if you selected a
mirroring array and wish to use two new assigned drives, follow the directions
here. After assigning new drives to a Mirroring array and saving the informa-
tion with <Ctrl-Y>, the window below will appear in order to create the array.
Confirm "N" or "No" to the message that follows as shown to proceed:
Do you want the disk image to be duplicated to another? (Yes/No)
Y - Create and Duplicate
N - Create Only
Adding Fault Tolerance to an Existing Drive
FastTrak66 will create a mirrored array using an existing system drive with
data. You must assign the existing drive and another drive of same or larger
capacity to the Mirroring array. The BIOS will send the existing data to the
new blank drive. Create the array by confirming "Y" or "Yes" to the message
that follows as shown below:
Do you want the disk image to be duplicated to another? (Yes/No)
Y - Create and Duplicate
N - Create Only
You will be prompted to select the Source drive from the two available drives.
Arrow down to the drive that has existing data to be mirrored and press [Enter]
to select.
Channel:ID
1 : Master
2 : Master
When prompted, press Y to confirm Yes to start duplicating the source image
to the target drive. Note: all target drive data will be erased. Make sure you
choose the correct drive.
Pagina 24
[Please Select A Source Disk]
Drive Model
MAXTOR87000A8
MAXTOR87000A8
24
Capacity (MB)
6522
6522
