FastBuild™ Configuration Setup
Fastbuild™ Utility 1.xx (c) 1995-99 Promise Technology, Inc.
Array No. RAID Mode Total Drv Capacity (MB)
Array 1 Stripe
Array 2 ------
Array 3 ------
Array 4 ------
NOTE: * -- Bootable Array
[ ] Up [ ] Down [ESC] Exit [ENTER] Select [Space] Change Boot Drive
NOTE: For most installations, Promise recommends the <1> Auto Setup
for easy disk array creation.
To manually create an array from the Define Array Menu above, use the arrow
keys to highlight an array number you wish to define, and press [Enter] to
select. The Define Array Definition Menu will next appear that allows drive
assignments to the disk array.
Define Array Definition Menu
Selecting an Array # from the Define Array Menu brings up the Define Array
Definition Menu screen. Under the Definition section, highlight the Array #
and use the [Space] key to cycle through three array types: Performance
(RAID 0 Striping), Fault Tolerance (RAID 1 Mirroring,
Striping/Mirroring (for 4 drives ), or Capacity (Spanning). See Auto Setup or
Chapter 5 about RAID levels.
Pagina 22
[ Define Array Menu ]
2 13440
------ ------
------ ------
------ ------
[Keys Available]
22
Status
Functional
------
------
------
RAID 0+1
