FastBuild™ Configuration Setup
Fastbuild™ Utility 1.xx (c) 1995-99 Promise Technology, Inc.
Array No. RAID Mode Total Drv Capacity (MB)
Array 1 Stripe
Stripe Block: 64KB
Channel: ID Drive Model
1 : Master MAXTOR87000A8
1 : Slave MAXTOR87000A8
2 : Master MAXTOR87000A8
[ ] Up [ ] Down [ESC] Exit [ENTER] Select [Space] Change Boot Drive
Drive Assignments Options
Under the [ Drive Assignments ] section, highlight a drive and with the [Space]
bar key change the Assignable option to "Y" to add the drive to the disk array.
Press <Ctrl-Y> to save the disk array information. Depending on the array type
selected, the following scenarios will take place:
1) If choosing a Striping, Spanning, or Mirroring/Striping array, the initial
Define Array Menu screen will appear with the arrays defined. From there
you may ESC to exit and return to the Main Menu of FastBuild.
2) If you selected a Mirroring array for two drives, there is an additional
window that appears as described in order to create the array. To do this you
will use either two brand new drives, or one drive that contains existing data
that you wish to mirror.
Pagina 23
[ Define Array Definition Menu ]
2 13044
[Drive Assignments]
Capacity (MB) Assignment
6522
6522
6522
[ Keys Available ]
23
Status
Functional
Y
N
Y
