[ 4 ] Starting the Operating System
See the steps below for a new operating system installation. For other suppor-
ted operating systems, see Chapter 7 for instructions.
1) Boot to Disk 1 of the DOS installation diskettes or manually partition and
format new drives with standard DOS FDISK and FORMAT utilities.
2) Install DOS, Windows, and/or Windows95/98 using the "Setup.exe" utility
found on the Microsoft installation diskettes.
Driver Installation
For DOS and Windows 3.1x: No drivers need to be installed. The FastTrak66
BIOS will provide enhanced operation.
Windows95/98 setup will show a "New Hardware Found" dialog box. Under
versions 4.00.950 and 4.00.950 an "Unknown PCI Device" will be detected.
Under versions 4.00.950 B "PCI RAID Controller" will be displayed.
NOTE: Obtain the Windows95/98 version number as follows: 1) Under the
My Computer icon, click Control Panel; 2) click the System icon. Note the
version number that appears here.
1) In the dialog box, choose "Driver from disk provided by hardware manu
facturer" button. In the a: drive, insert the FastTrak66 utility diskette and
type in "A:\" where prompted for the directory.
2) Select "Promise Technology, Inc. PCI FastTrak66 Driver" and click on
Next. The FastTrak66 driver is now copied onto the system and entered into
the Windows95/98 driver database.
3) When the "System Settings Change" dialog box appears, remove the floppy
diskette and click on "Yes" to restart the system. Windows95/98 will then
restart for the driver installation to take effect.
Confirming Windows95/98 Installation
From Windows95/98, open the Control Panel from My Computer followed by
the System icon. Choose the "Device Manager" tab and click the "+" in front
of the "SCSI Controllers" hardware type. The driver "Promise Technology, Inc.
PCI FastTrak66 Driver" driver should be installed.
