13.2. Commissioning
The laryngeal mirrors can only be used in combination with the lamp holder.
This ensures optimal illumination. Take one of the 2 laryngeal mirrors and at-
tach it to the front of the lamp holder in the desired direction.

14. Operating otoscope for veterinary medicine

Device function:
3 2 1 4
1) Ear speculum holder
2) Lamp
3) Magnifying glass
4) Bayonet mount
14.1. Purpose/indication
The Riester operating otoscope described in this user manual is produced
exclusively for use on animals or for veterinary medicine and therefore has no
CE marking. It can be used for illumination and examination of the auditory
canal, as well as for minor operations in the auditory canal.

14.1.1. Contraindication:

There may be a risk of ignition of gases if the instrument is used in the presence
of flammable mixtures or mixtures of pharmaceuticals.
The instrument heads and battery handles must never be placed in liquids.
The product and the ear specula are non-sterile. Do not use on injured tissue.
Use new or sanitised ear specula to limit the risk of cross-contamination.
Used ear specula must be disposed of in accordance with current medical
practices or local regulations regarding the disposal of infectious, biological
medical waste.
Only use Riester or Riester-approved accessories/consumables.
Cleaning frequency and sequence must comply with the cleaning regulations of
non-sterile products in the respective facility. Cleaning/disinfection instructions
in the instructions for use must be observed.
The product may only be used by trained personnel.

14.1.2. Intended patient population:

The device is intended for adults and children.

14.1.3. Intended operators/users:

The otoscopes are intended exclusively for use by doctors in clinics and medical
practices.

14.1.4. Required skills/operator training:

Since only doctors use the otoscopes, they have the appropriate qualifications.

14.1.5. Environmental conditions:

The device is intended for use in rooms with a controlled environment. The de-
vice must not be exposed to adverse/harsh environmental conditions.
14.2. Attaching and removing ear specula for veterinary medicine
Place the required speculum on the black holder of the operating otoscope so
that the recess on the speculum fits into the guide in the holder. Fasten the
speculum by turning it clockwise.
14.3. Swivel magnifying lens for enlarging
There is a small 360° swivel magnifying lens on the operating otoscope with a
magnification power of about 2.5 times.
14.4. Inserting external instruments into the ear
The operating otoscope has an open design so that external instruments can
be inserted into the ear.
14.5. Technical data for the lamp
Operating otoscope HL 2.5 V 2.5 V 680 mA avg.lifespan 20 h
Operating otoscope XL 3.5 V 3.5 V 700 mA avg.lifespan 20 h
