3.3 Switching the device ON and OFF

Switching the device ON:
The device is activated by pressing the [ON/OFF] key
(approx.2sec). Subsequently, the device is checked,
rinsed and filled automatically.
Automatic start sequence of device:
Switching the RO unit ON
BWT PERMAQ bestaqua
Internal function check of sensors,
Autotest
electronics and pump
Filling the feed water into the RO unit
WATER FILL-UP
Automatic rinsing of the RO unit
RINSING
The RO unit shifts automatically to the main menu "START".
Main menu "Start":
START
Ready: press
Fig. 6: Display: Main menu: "Ready: Press
Attention: Prior the initial start-up, ensure that the device
has been checked for correct installation.
The system switches to the "Starting" status by tapping
the [ ] confirmation key and is ready for operation.
Note: The production starts automatically as permeate
is demanded (pressure drop on the permeate side).
Only if needed: In the course of first commissioning the permeate
conductivity should be set via the blending valve, see Part 3.10.
Switching the device "Standby":
Brief pressing of the [ON/OFF] key, the device switches
to standby. The device is immediately available for
operation after reactivation.
to st a r t
to start"
Switching the device OFF:
Deactivate the device completely by pressing the
[ON/OFF] key for about 2s on the control unit.

3.4 Menu display of the activated system

PERMEATE 1975 ml / min
CONCENTRATE 1190 ml / min
WCF SET POINT 62 %
PUMP PRESS 13.4 bar
=
PERM PRESS 1.1 bar
Fig. 7: Display: Activated menu "Start" at process step: Working
Status after activation the "Start" menu:
RO unit starts
Starting:
Permeate production is activated
Working:
Ready for a new consumption demand
Ready:
Note: The display always switches OFF after about
120s. A brief pressing of any key re-activates the
display.

3.5 System settings/functions

Note: All of the settings described in Part 3.8 can only
be accessed and activated in the "Ready" mode and
the "START" menu of the device.
During operation mode "Working" are any parameter
settings NOT possible.
Visualisation of the menu screens/displays:
Note: The differing representation of the software
diagrams exclusively serves a better overview and is
subsequently described.
Bold black writing is subsequently used to highlight respectively
activated menu items or data input. The
are represented in
dark grey.
GENERAL
PRESSURE
Blue fields = Menu item of a main menu, that contains
further sub-menus or parameter inputs.
White fields, in grey writing = inactive menu.
Black writing, bold = active menu line or input value.
= inactive menu line or input value.
Dark grey writing
COND 12μS
TEMP 17°C
WCF 62%
Starting
Working
Working
Ready
items
inactive menu
ACTIVE
INACTIVE
