Status Rl - gefran GPC Programmieranleitung

3.19.4.

Status rL

Adresse
Ein- Mehr-
Format
zelkno- fach-
ten knoten
1036
2060 12 bit
4108
1037
2061 13 bit
4109
1038
2062 14 bit
4110
1039
2063 15 bit
4111
1040
2064 16 bit
4112
1041
2065 17 bit
4113
Das Bit zeigt den Status der Referenzsignale rL.1...rL.6 der GPC-M-, GPC-E1- und GPC-E2-Module, abhängig von der verwendeten
Adresse.
Optionen: OFF = Signal deaktiviert
ON
= Signal aktiviert
GPC-
Abkür-
OP-
zung
Menü
M
BIT_
STA-
E1
TUS_
RL1
E2
M
BIT_
STA-
E1
TUS_
RL2
E2
M
BIT_
STA-
E1
TUS_
RL3
E2
M
BIT_
STA-
E1
TUS_
RL4
E2
M
BIT_
STA-
E1
TUS_
RL5
E2
M
BIT_
STA-
E1
TUS_
RL6
E2
81901A „MSW_GPC-40/600A"_03-2021_DE_pag. 87
Menü GF_eXpress
Beschreibung
MainMenu → M → Expert →
Bit → BIT_STATUS_RL1_1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL1_2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL1_3
MainMenu → M → Expert →
Bit → BIT_STATUS_RL2_1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL2_2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL2_3
MainMenu → M → Expert →
Bit → BIT_STATUS_RL3_1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL3_2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL3_3
MainMenu → M → Expert →
Bit → BIT_STATUS_RL4_1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL4_2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL4_3
MainMenu → M → Expert →
Bit → BIT_STATUS_RL5_1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL5_2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL5_3
MainMenu → M → Expert →
Bit → BIT_STATUS_RL6_1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL6_2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL6_3
