5.4.
Menüstruktur
5.4.1.
Hauptmenü und Menü der 2. Ebene
MAIN MENU
00
CURRENT LIMIT
01
STATUS
02
INFO
03
COMMS
04
INPUTS
05
ALARMS
06
OUTPUTS
07
CONTROLS
08
SPECIAL FUNCTIONS
09
POWER CONTROLS
10
VIRTUAL
11
CUSTOM MAP
12
COMMANDS
01 STATUS
01.01 STATUS GLOBAL
01.02 STATUS M
01.03 STATUS E1
01.04 STATUS E2
03 COMMS
03.01 SETTINGS GLOBAL
03.02 SETTINGS M
03.03 SETTINGS E1
03.04 SETTINGS E2
04 INPUTS
04.01 STATUS GLOBAL
04.02 STATUS M
04.03 STATUS E1
04.04 STATUS E2
04.05 ANALOG In.A1
04.06 ANALOG In.A2
04.07 ANALOG In.A3
04.08 CT M
04.09 VT line M
04.10 VT load M
04.11 CT E1
04.12 VT line E1
04.13 VT load E1
04.14 CT E2
04.15 VT line E2
04.16 VT load E2
04.17 DIGITAL
07 CONTROLS
07.01 SETTINGS GLOBAL
07.02 SETTINGS M
07.03 SETTINGS E1
07.04 SETTINGS E2
08 SPECIAL FUNCTIONS
08.01 SETTINGS
10 VIRTUAL
10.01 SETTINGS
11 CUSTOM MAP
11.01 SETTINGS
12 COMMANDS
12.01 COMMANDS M
12.02 COMMANDS E1
12.03 COMMANDS E2
81901A „MSW_GPC-40/600A"_03-2021_DE_pag. 144
00 CURRENT LIMIT
00.01 CURRENT LIMIT M
S. 145
00.02 CURRENT LIMIT E1
00.03 CURRENT LIMIT E2
02 INFO
02.01 UPd: sw version
S. 146
02.02 C.Hd: hardware conf
02.03 C.Hd1: hardware conf
02.04 C.Hd2: hardware conf
02.05 C.Hd3: hardware conf
02.06 C.Hd4: hardware conf
02.07 JUMPER_STATUS:
02.08 OPTION: installed
S. 146
02.09 Cod: serial code
02.10 UPd.F: fieldbus vers
02.11 Cod.F: fieldbus code
02.12 bAu.F: fieldbus baud
05 ALARMS
05.01 AL1...AL8 M
05.02 AL1...AL8 E1
05.03 AL1...AL8 E2
05.04 HB M
05.05 HB E1
05.06 HB E2
05.07 PF M
05.08 PF E1
05.09 PF E2
06 OUTPUTS
06.01 REFERENCE RL M
S. 149
06.02 REFERENCE RL E1
06.03 REFERENCE RL E2
06.04 PHYSICAL OUT
06.05 ANALOG Out.A1
06.06 ANALOG Out.A2
06.07 ANALOG Out.A3
S. 149
06.08 LED
09 POWER CONTROLS
09.01 SSR MODE M
S. 150
09.02 SSR MODE E1
09.03 SSR MODE E2
09.04 FIRING CHANG M
S. 151
09.05 FIRING CHANG E1
09.06 FIRING CHANG E2
09.07 HEURISTIC
S. 151
09.08 HETEROGENEOUS
S. 145
S. 147
S. 148
S. 150
