Low Priority Errors - Inogen ONE G5 Technisches Servicehandbuch

Concentrator runs on
battery power when
plugged into the CLA
in a car
A battery is installed
but the battery icon
does not appear on
the LCD screen

5.3. LOW PRIORITY ERRORS

The following low priority error messages are accompanied by a double beep and a solid yellow LED.
Display Text Equivalent
Battery Low
Attach Plug
Remove Battery
To Cool
CONFIDENTIAL
96-09302-00-01 rev C
and PROPRIETARY
Low Input Voltage Ensure that the car is running and that the input to the system
from car is greater than 12V DC.
OR Cigarette lighter outlet must be capable of 10A load. The
power outlet should be rated at 120 W 12V.
Blown car fuse
Try an alternate DC cord or power outlet in the car or have a
dedicated power outlet installed by an auto mechanic.
The concentrator Turn off the concentrator and remove the battery and remove
cannot the power plug from the concentrator. Reinstall the battery
communicate with and the power plug. Verify that the battery charges or
the battery indicates battery full. If the battery does not charge or indicate
it is fully charged while the concentrator is in standby mode,
try a different battery. If the concentrator will not respond to a
known good battery, replace the concentrator.
Condition
The battery attached to
the concentrator is
depleted or bad
The battery temperature
has exceeded the
temperature limit for at
least 30 minutes while
battery is charging on
concentrator.
DCR 20-328 08-OCT-2020
Action/Explanation
Charge the battery and try again. If the
problem persists, try a new battery. If the
concentrator will not respond to a known good
battery, replace the concentrator.
Remove battery to cool. If charging is desired,
charge the battery in the external charger while
powering the unit with the external power
supply. If the condition recurs, replace the
concentrator.
INOGEN ONE G5 TECHNICAL MANUAL
Page 16 of
42
