Parts List
Ersatzteileliste
Parts List
Parts #
Description
6274
PRECUT FOAM BUMPER GRAY (RS4)
6563
RACING SHOCK SPRING 14x25x1.5mm 6.5COILS(SIL/2pcs)
6820
SILICONE O-RING P-3 (CLEAR/8pcs)
6987
SPUR GEAR 87 TOOTH (48 PITCH/CARBON FIBER)
61051
39 TOOTH PULLEY (ONE-WAY)
61059
CYCLONE WORLD CHAMPION DECAL
61086
FRONT SOLID AXLE SET Ver.3 (BLACK)
61090
FRONT SHOCK TOWER WORLD CHAMPION EDITION 3.5mm
61091
REAR SHOCK TOWER WORLD CHAMPION EDITION 3.5mm
61092
WHEEL NUT M4 SERRATED (PURPLE/4pcs)
61148
DIFF THRUST WASHER 2.8x5.8x1mm (2pcs)
61149
DIFFERENTIAL THRUST BALL 1/16"
61237
BEARING HOLDER PARTS
61246
TURNBUCKLE 3x24mm (2pcs)
61324
SPUR HOLDER (PURPLE)
61327
CYLINDER UPPER CAP (PURPLE/2pcs)
61328
CYLINDER LOWER CAP (PURPLE)
61338
44mm ALUMINUM UNIVERSAL DOGBONE (PURPLE)
61611
TURNBUCKLE SHAFT (3x16mm/2pcs)
61627
DIFF RING (2pcs)
61761
MAIN CHASSIS 2.5mm
61762
REAR UPPER DECK/STEERING POST TOWER BAR SET
61763
FRONT UPPDER DECK
61765
STEERING POST
61766
STEERING CRANK R
61767
STEERING CRANK L
61768
STEERING CRANK C
61769
STEERING CRANK SPACER (4x3x1mm)
61770
MOTOR MOUNT L
61771
MOTOR MOUNT R
61772
MOTOR MOUNT POST
61773
CENTER SHAFT
61774
REAR BELT TENTIONER
61775
TURNBUCKLE 3x50mm (1pc)
61777
FRONT BELT 216 (72T)
61778
REAR BELT 501 (167T)
66492
CENTER PULLEY 18T
67729
DIFFERENTIAL BALL 3.0mm (12pcs Bag)
67706
FRONT BULK HEAD SET (PURPLE)
67708
REAR BULK HEAD SET (PURPLE)
67712
UPPER BULK HEAD SET (PURPLE)
67716
SHOCK BODY (2pcs)
67717
GRAPHITE SUSPENSION ARM SET
67721
39T PULLEY (PRO SPEC BALL DIFF)
67723
CUP JOINT (POM/PRO SPEC BALL DIFF)
67725
DIFF SCREW SET (PRO SPEC BALL DIFF)
73507
CARBON GRAPHITE BLOCK AND HUB SET
73510
SHOCK PARTS/BALL END SET
73513
BUMPER/BODY POST SET
73518
CARBON GRAPHITE C HUB SET (4 DEGREES)
73523
BLADDER 12x3.5mm (FLAT TYPE/4pcs)
75106
BODY CLIP (6mm/BLACK/20pcs)
75115
BALL STUD 4.3x10.3mm (2mm SOCKET/4pcs)
75116
BALL STUD 4.3x13mm (2mm SOCKET/4pcs)
75119
SUSPENSION SHAFT 2.5x24.5mm (2pcs)
75121
PIVOT BALL 3x5mm (4pcs)
75122
STEERING BLOCK BUSHING (4pcs)
75151
PIVOT BLOCK F/R (ALUMINUM/PURPLE)
75156
PIVOT BLOCK 0 DEGREES (ALUMINUM/PURPLE)
75160
PIVOT BLOCK 2 DEGREES (ALUMINUM/PURPLE)
75187
UNIVERSAL AXLE (2pcs)
75188
UNIVERSAL REBUILD KIT (2pcs)
85083
BATTERY HOLDER PARTS
85084
STEERING LINKAGE
100556
FLAT HEAD SCREW M3x14mm (HEX SOCKET/10pcs)
A165
SPRING 6x7x1.5mm (DIFFERENTIAL) BLACK (2pcs)
A302
HEAVY-DUTY BALL CUP 4.3x18mm (8pcs)
B012
BALL BEARING 3x6x2.5mm (FLANGED/2pcs)
B017
BALL BEARING 4x8x3mm (2pcs)
B020
BALL BEARING 5x8x2.5mm (2pcs)
B021
BALL BEARING 5x10x4mm (2pcs)
B030
BALL BEARING 10x15x4mm (2pcs)
HB70708
STEERING ARM SET (CYCLONE)
HB70712
SHAFT 3x45mm, 2pcs (CYCLONE)
HB70716
ANTENNA POST (CYCLONE)
HB70720
CYLINDER NUT (BLACK/2pcs)
HB70721
HIGH GRADE SHOCK SHAFT, 28mm, 2pcs (CYCLONE)
HB70722
SHOCK PISTON (1.2), 2pcs (CYCLONE)
HB70723
ROD GUIDE, 2pcs (CYCLONE)
HB70742
ALUMINUM HEX HUB SET (CLAMP TYPE/4pcs/CYCLONE)
Z082
FLAT HEAD SCREW M3x8mm (HEX SOCKET/10pcs)
Z083
FLAT HEAD SCREW M3x10mm (HEX SOCKET/10pcs)
Z150
ANTENNA PIPE SET
Z155
DIFFERENTIAL LUBE (SILICONE)
Z156
GRAY DIFFERENTIAL LUBE (FOR DIFF SMALL BALLS)
Z203
WASHER M3x6mm (10pcs)
Z216
BUTTON HEAD SCREW M3x15mm (HEX SOCKET/4pcs)
Z234
CAP HEAD SCREW M2x5mm (10pcs)
Z242
E CLIP E2mm (20pcs)
Z243
E CLIP E3mm (10pcs)
Z264
PIN 2x10mm SILVER (10pcs)
Z305
SCREW POST M3x15mm (4pcs)
Z350
BUTTON HEAD SCREW M3x5mm (HEX SOCKET/10pcs)
Z352
BUTTON HEAD SCREW M3x8mm (HEX SOCKET/10pcs)
Z353
BUTTON HEAD SCREW M3x10mm (HEX SOCKET/10pcs)
Z354
BUTTON HEAD SCREW M3x12mm (HEX SOCKET/10pcs)
Z356
BUTTON HEAD SCREW M3x18mm (HEX SOCKET/10pcs)
Z653
NUT M3 (6pcs)
Z676
LOCK NUT M3 THIN TYPE (4pcs)
Z700
SET SCREW M3x3mm (6pcs)
Z724
SET SCREW M4x8mm (ROUND POINT/6pcs)
Z775
SET SCREW TP3.2x5mm (6pcs)
Z814
ALUMINUM WASHER 3x6x0.75mm (PURPLE/10pcs)
Z817
ALUMINUM WASHER 3x6x2.0mm (PURPLE/10pcs)
Z852
WASHER 5x7x0.2mm (10pcs)
Z901
ALLEN WRENCH 1.5mm
Z904
ALLEN WRENCH 2.0mm
Z950
CROSS WRENCH (SMALL)
Z960
TURNBUCKLE WRENCH 4mm/5.5mm
Liste de pièces
パーツリスト
Ersatzteileliste
Nummer
Beschreibung
6274
ANGEPASSTER RAMMER GRAU (RS4/CYCLONE)
6563
DAEMPFERFEDER RACING 14x25x1.5mm 6.5Wdg. (SIL/2ST)
6820
SILIKON O-RING P-3 (TRANSPARENT/8ST)
6987
87Z HAUPTZAHNRAD 48dp
61051
RIEMENRAD 39Z (FREILAUF/CYCLONE)
61059
CYCLONE WORLD CHAMPION DECALS
61086
STARRACHSE VORNE VER.3 (SCHWARZ/CYCLONE)
61090
DAEMPFERVRUECKE VORNE 3.5mm WCE (CYCLONE)
61091
DAEMPFERBRUECKE HINTEN 3.5mm WCE (CYCLONE)
61092
RADMUTTER M4 (GERIFFELT/LILA/4ST)
61148
DRUCKLAGERSCHEIBEN 2.8x5.8x1mm (2ST)
61149
DRUCKLAGERKUGELN 1/16
61237
LAGERHALTER TEILE (CYCLONE S)
61246
SPURSTANGE 3x24mm (2 ST/CYCLONE S)
61324
HAUPTZAHNRAD HALTERUNG (LILA/CYCLONE)
61327
DAEMPFERKAPPE OBEN (LILA/2ST)
61328
DAEMPFERKAPPE UNTEN (LILA/2ST)
61338
ALU KARDAN 44mm (LILA/CYCLONE)
61611
STURZSTREBE (3x16mm/2ST/CYCLONE 12)
61627
DIFFERENTIAL-RINGE (2ST/CYCLONE)
61761
CHASSIS 2.5mm (CYCLONE TC-D)
61762
TOPDECK HINTEN/LENKUNGSBRUECKE SET (CYCLONE TC-D)
61763
TOPDECK VORNE (CYCLONE TC-D)
61765
LENKUNGSPFOSTEN (CYCLONE TC-D)
61766
LENKHEBEL R (CYCLONE TC-D)
61767
LENKHEBEL L (CYCLONE TC-D)
61768
LENKHEBEL C (CYCLONE TC-D)
61769
LENKHEBEL HUELSE 4x3x1mm (CYCLONE TC-D)
61770
MOTORHALTER L (CYCLONE TC-D)
61771
MOTORHALTER R (CYCLONE TC-D)
61772
MOTORHALTER-PFOSTEN (CYCLONE TC-D)
61773
MITTELWELLE (CYCLONE TC-D)
61774
RIEMENSPANNER HINTEN (CYCLONE TC-D)
61775
SPURSTANGE 3x50mm (1ST)
61777
FRONTRIEMEN 216 (72Z/CYCLONE TC-D)
61778
RIEMEN HINTEN 501 (167Z)
66492
RIEMENRAD MITTELWELLE 18Z (CYCLONE)
67729
DIFFERENTIALKUGELN 3.0mm (12ST/CYCLONE/TC)
67706
DIFFGEHAEUSE SET VORNE (LILA/CYCLONE TC)
67708
DIFFGEHAEUSE SET HINTEN (LILA/CYCLONE TC)
67712
OBERES DIFFGEHAEUSE SET (LILA/CYCLONE TC)
67716
DAEMPFERGEHAEUSE (2ST/CYCLONE TC)
67717
SCHWINGEN SET (KOHLEFASERVERSTAERKT/CYCLONE TC)
67721
RIEMENRAD 39Z (PRO SPEC DIFF)
67723
DIFFERENTIAL CUP JOINT SET (POM/PRO SPEC DIFF)
67725
DIFFERENTIAL SCHRAUBE M2.6x31mm (PRO SPEC DIFF)
73507
LENKHEBEL/TRAEGER (KOHLEFASERVERSTAERKT)
73510
DAEMPFERTEILE/KUGELKOPF SET
73513
RAMMER/KAROSSERIEHALTER SET
73518
LENKHEBELTRAEGER (4 GRAD/KOHLEFASERV.)
73523
DAEMPFERMEMBRAN 12x3.5mm (FLACH/4 ST)
75106
KAROSSERIEKLAMMERN (6mm/SCHWARZ/20ST)
75115
KUGELKOPF 4.3X10.3mm (2mm INBUS/4ST)
75116
KUGELKOPF 4.3x13mm (2mm INBUS/4ST)
75119
ACHSSTIFTE 2.5x24.5mm (2ST)
75121
KUGELKOPF 3x5mm (4ST)
75122
LENKUNGSLAGER (4ST)
75151
QUERLENKERHALTER V/H (ALUMINIUM/LILA)
75156
QUERLENKERHALTER 0 GRAD (ALU/LILA)
75160
QUERLENKERHALTER 2 GRAD (ALU/LILA)
75187
KARDAN ACHSE (2ST/PRO4/CYCLONE)
75188
KARDAN WARTUNGS SET (2ST/PRO4/CYCLONE)
85083
AKKUHALTER TEILE (CYCLONE TC-D)
85084
LENKGESTAENGE (CYCLONE TC-D)
100556
SENKKOPFSCHRAUBE M3x14mm (INBUS/10ST)
A165
DIFF-FEDER 6x7x1.5mm SCHWARZ (2 St.)
A302
KUGELPFANNE 4.3x18mm (8 St.)
B012
KUGELLAGER 3x6x2.5mm (MIT FLANSCH/2ST)
B017
KUGELLAGER 4x8x3mm (2ST)
B020
KUGELLAGER 5x8x2.5mm (2ST)
B021
KUGELLAGER 5x10mm (2ST)
B030
KUGELLAGER 10x15x4mm (2ST)
HB70708
SERVO SAVER WARTUNGS SET (CYCLONE)
HB70712
ACHSSTIFT 3x45mm (2ST/CYCLONE)
HB70716
ANTENNENHALTER (CYCLONE)
HB70720
DAEMPFER EINSTELLMUTTER (SCHWARZ/2ST/CYCLONE)
HB70721
KOLBENSTANGE HIGH GRADE 28mm (2ST/CYCLONE)
HB70722
KOLBENPLATTEN (2L/1,2mm/2ST/CYCLONE)
HB70723
KOLBENSTANGENFUEHRUNGSSATZ (2ST/CYCLONE)
HB70742
ALU FELGENMITNEHMER ZUM KLEMMEN (CYCLONE)
Z082
SENKKOPFSCHRAUBE M3x8mm (INBUS/10ST)
Z083
SENKKOPFSCHRAUBE M3x10mm (INBUS/10ST)
Z150
ANTENNENROHRSET
Z155
DIFFERENTIAL FETT
Z156
GRAUES DIFFERENTIALFETT
Z203
M3x6 UNTERLAGSCHEIBE (10ST)
Z216
FLACHKOPFSCHRAUBE M3x15mm (INBUS/4ST)
Z234
INBUSSCHRAUBE M2x5mm (10ST)
Z242
E-CLIP E2mm SILBER (20ST)
Z243
E-CLIP E3mm (10ST)
Z264
STIFT 2x10mm SILBER (10ST)
Z305
SCHRAUBENPFOSTEN M3x15mm (4ST)
Z350
FLACHKOPFSCHRAUBE M3x5mm (INBUS/10ST)
Z352
FLACHKOPFSCHRAUBE M3x8mm (INBUS/10ST)
Z353
FLACHKOPFSCHRAUBE M3x10mm (INBUS/10ST)
Z354
FLACHKOPFSCHRAUBE M3x12mm (INBUS/10ST)
Z356
FLACHKOPFSCHRAUBE M3x18mm (INBUS/10ST)
Z653
MUTTER M3 (6ST)
Z676
STOPPMUTTER M3 (FLACH) (4ST)
Z700
MADENSCHRAUBE M3x3mm (6ST)
Z724
MADENSCHRAUBE M4x8mm (6ST)
Z775
MADENSCHRAUBE TP3. 2x5mm (6ST)
Z814
ALUMINIUM UNTERLAGSCHEIBE 3x6x0.75mm (LILA/10ST)
Z817
ALUMINIUM UNTERLAGSCHEIBE 3x6x2.0mm (LILA/10ST)
Z852
UNTERLAGSCHEIBE 5x7x0.2mm (10ST)
Z901
INBUSSCHLUESSEL 1.5mm
Z904
INBUSSCHLUESSEL 2.0mm
Z950
KREUZSCHLUESSEL KLEIN
Z960
SPURSTANGENSCHLUESSEL 4mm/5.5mm
40
