Parts List

Ersatzteileliste
Parts List
En
Parts # Description
6122 Body Pin (6mm/Silver/Medium/20pcs)
6163 Servo Tape 20x100mm (10pcs)
6203 Body Clip (8mm/Black/20pcs)
6561 Spring 18x20x1.7x5 (Black/2pcs)
6811 O-Ring 6x9.5x1.9mm (Black/8pcs)
6899 O-Ring 5x8x1.5mm (6pcs)
67492 17mm Wheel Nut (Black/4pcs)
68186 HD Fuel Tube 300mm
72130 Stainless Steel Slipper Plate
72131 Slipper Clutch Pad (2pcs)
72367 Brake Spring 4x5x20mm (2pcs)
75075 Silicone O-Ring S4 (3.5x2mm/12pcs)
75080 O-Ring 7x11x2.0mm (Black/8pcs)
77054 Spur Gear 44 Tooth (Savage 3 Speed)
77058 Pinion Gear 18 Tooth (Savage 3 Speed)
77107 Racing Clutch Bell 17 Tooth (1M)
77127 Heavy Duty Spur Gear 47 Tooth
80575 Receiver Switch
85048 Upright Set
85050 Shock Parts And Rod End Set (2 Shocks)
85052 Centre Gear Box Case
85058 Steering Crank/Servo Saver Set
85231 Shock Spacer Parts Set
85234 Skid Plate/Body Mount/Shock Tower Set
85235 Gear Box/Bulkhead Set
85236 Radio Box Set
85237 Radio Box Parts Set
85238 Suspension Arm Set
86054 Dogbone 8x142mm (Black)
86057 Dogbone 8x78mm (Black)
86059 Ball 6.8x7.3x3mm (Black/4pcs)
86060 Engine Mount
86071 Flange Shaft 4x62mm (Black/2pcs)
86073 Shaft 4x78mm (Silver/2pcs)
86074 Shaft 4x46mm (Silver/2pcs)
86077 Collet 7x6.5mm (Brass/21 Size/2pcs)
86079 Engine Mount Brace 7x7x74mm (2pcs)
86081 Gear Shaft 6x12x78mm (Black/1pc)
86083 Cup Joint 8x19mm (Black/1pc)
86089 Drive Shaft 6x70mm (Black/1pc)
86090 Steering Crank Post 6x49mm (Black/2pcs)
86094 Screw Shaft M4x2.5x12mm (Black/6pcs)
86095 Screw Shaft M5x3x18mm (Black/6pcs)
86099 Diff Case Washer 0.7mm (6pcs)
86130 Slipper Clutch Hub (Savage)
86138 Aluminium Tuned Pipe (Polished/21+)
86171 Metal Spacer Set 5x7.5x3mm
86246 Super Heavy Duty Drive Shaft 11x123mm (2pcs)
86247 Exhaust Header (Silver)
86248 Super Heavy Duty Diff Shaft 9x11x34mm (2pcs)
86271 Flywheel 34mm (3Pin)
86322 Cup Joint 6x19x21mm
86356 Brake Linkage Set
86362 Clutch Gear Hub (Savage 3 Speed)
86551 Shock Spring 18x80x1.8mm 14.5 Coils (Pink 134Gf/mm)
86803 Joint Post 4x6x74mm
86827 Alloy Diff Case
86930 Steel Brake Cam / Piston Set (Black)
86972 Washer 6x15x0.2mm (6pcs)
86996 Aluminum Mount And Retainer Set (Savage XL)
87027 Rubber Cap 10x11mm (Black)
87042 Spring 4.9x8x7mm/Washer 4.3x10x1.0mm(Hex Hole) Set
87043 Rubber Cap For Gear Box (2pcs)
87052 Silicone Exhaust Coupling 15x25x40mm (Black)
87054 Exhaust Manifold Spring 4,9x76x0,7 mm (2pcs)
87055 Dual Fiberglass Brake Disk 19x35x2.5mm/ Plate Set
87058 Rubber Tube 3x8 10mm (Shaped/Black/8pcs)
87149 Racing Fuel Tank (160Cc/No Primer)
87193 4 Bevel Gear Differential Conversion Set (1 Set)
87194 Shaft For 4 Bevel Gear Diff 4x27mm (4pcs)
87198 Air Cleaner (21+ Size)
87199 Air Cleaner Sleeve (For #87198)
87204 Air Cleaner Foam Element Set (For #87198)
87500 Bladder 16x5mm (Flat Type/4pcs)
87524 Rubber Bump Stop (4pcs)
87546 Glow Plug Wrench (7/8/10/17mm)
93535 Turnbuckle M4x70mm (4pcs)
94305 TP. Flat Head Screw M3x12mm (Hex Socket/10pcs)
94354 TP. Button Head Screw M3x10mm (Hex Socket/10pcs)
94398 Cap Head Screw M3x55mm (6pcs)
94554 Button Head Screw M4x10mm (Hex Socket/10pcs)
94631 TP. Flat Head Screw M4x15mm (Hex Socket/10pcs)
100559 Button Head Screw M3x14mm (Hex Socket/10pcs)
100948 Shock Body Set (113-157mm)
100949 Shock Parts Set
100950 Shock Shaft 3.5x90mm (4pcs)
100961 Shock Cap Set
102365 Big Bore Sport Shock Set (Assembled/Savage)
102526 Roll Cage Set (Savage XL)
102692 Machined Bulletproof Diff Bevel Gear 29T/9T Set
Liste de pièces
パーツリスト
Parts # Description
105891 Upper Arm Brace 4x54x3mm (Orange/2pcs)
105892 Bulkhead Lower Plate 2.5mm (Orange)
105893 Lower Arm Brace 4x54x3mm (Orange/2pcs)
105894 Steering Post 12x47mm (Orange)
105895 Shaped Exhaust Gasket (Black/2pcs)
111094 Third Gear Clutch Holder 6x21x5.3mm
111097 Second Gear Clutch Holder 6x21x5mm
111167 Idler Gear 31Tx1M (Steel)
111169 Drive Gear 30Tx1M (Steel)
113002 Spacer 8x12x14mm (Gunmetal/4pcs)
160108 GT-6 Body Accessory Set
160112 TVP Chassis Set (Savage XL 5.9/Gunmetal)
160113 Engine Plate 3.0mm (Orange)
160122 Bumper Set
160137 Super HD XL Axle 8x11x57mm (2pcs)
160138 17mm Hex Hub Adaptor (Orange/2pcs)
160139 Cup Joint 6x13x20mm (2pcs)
160141 Savage XL 17mm Hex Hub Conversion Set
160147 Havok Wheel Black (3.8inx71mm/2pcs)
160312 Step Screw M3x19mm (Hex Socket/4pcs)
160313 Step Screw M3x14mm (Hex Socket/4pcs)
160314 Step Screw M3x20mm (Hex Socket/4pcs)
160315 Step Screw M4x20mm (Hex Socket/4pcs)
160316 TP. Flanged Screw M2.6x12mm (Hex Socket/6pcs)
160320 Aluminum Clutch Shoe/1.0mm Spring Set (3pcs)
160361 Wheel Wrench Extender (17mm)
160362 Cross Wrench Small (Plastic)
160364 Turnbuckle Wrench
160366 GTXL-6 Kingcab Clear Truck Body (Savage XL)
160402 Washer 6x9x2.9mm (2pcs)
160403 Clutch Nut 1/4-28x8.5mm (Black)
160404 Washer 6x9x0.5mm (10pcs)
160584 Tredz TerraHex Tire HD 160x90/3.8in (2pcs)
160593 TP. Flat Head Screw M3x18mm (Hex Socket/10pcs)
160594 TP. Flat Head Screw M3x25mm (Hex Socket/10pcs)
160595 TP. Flat Head Screw M4x30mm (Hex Socket/10pcs)
160597 TP. Button Head Screw M3x15mm (Hex Socket/10pcs)
160598 TP. Button Head Screw M4x10mm (Hex Socket/10pcs)
160599 TP. Button Head Screw M4x16mm (Hex Socket/10pcs)
160755 Savage 3 Speed HD Gear Set (Second Gear 21/41T)
160756 Savage 3 Speed HD Gear Set (Third Gear 26/36T)
160799 Washer 6x9x0.2mm (10pcs)
160944 Engine Spacer 1mm
B021 Ball Bearing 5x10x4mm (2pcs)
B023 Ball Bearing 6x13x5mm (2pcs)
B025 Ball Bearing 6x10F
B032 Ball Bearing 10x16x5mm (2pcs)
B085 Ball Bearing 8x16x5mm (2pcs)
Z081 Flat Head Screw M3x6mm (Hex Socket/10pcs)
Z082 Flat Head Screw M3x8mm (Hex Socket/10pcs)
Z085 Flat Head Screw M3x15mm (Hex Socket/10pcs)
Z086 Flat Head Screw M3x18mm (Hex Socket/10pcs)
Z150 Antenna Pipe Set
Z216 Button Head Screw M3x15mm (Hex Socket/4pcs)
Z224 Washer M3x8mm (10pcs)
Z240 C Clip 8mm (4pcs)
Z243 E-Clip E3mm (10pcs)
Z245 E Clip E5mm (10pcs)
Z260 Pin 2.5x12mm (12pcs)
Z272 Pin 2.5x17mm (8pcs)
Z303 Cap Head Screw M3x42mm (Black/6pcs)
Z350 Button Head Screw M3x5mm (Hex Socket/10pcs)
Z352 Button Head Screw M3x8mm (Hex Socket/10pcs)
Z356 Button Head Screw M3x18mm (Hex Socket/10pcs)
Z542 Cap Head Screw M3x8mm (12pcs)
Z543 Cap Head Screw M3x10mm (6pcs)
Z544 Cap Head Screw M3x12mm(6pcs)
Z547 Cap Head Screw M3x20mm (Black/6pcs)
Z562 TP. Flanged Screw M3x10mm
Z661 Lock Nut M2.6 (4pcs)
Z663 Lock Nut M3 (6pcs)
Z684 Flange Lock Nut M4 (4pcs)
Z685 Washer 2.7x6.7x0.5mm (10pcs)
Z694 Washer M5x10x0.5mm (10pcs)
Z695 Washer 4x6x0.3mm (10pcs)
Z721 Set Screw M4x4mm (4pcs)
Z740 Set Screw M5x4mm Black
Z741 Set Screw M5x5mm (4pcs/Black)
Z792 Cap Head Screw M4x8mm (6pcs)
Z877 Washer 8x10x0.2mm (10pcs)
Z892 Washer 10x12x0.2mm (10pcs)
