VIEWEG
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
External Program select: (assumed by REMOTE input signal)
Program Nr.
Manual
Program 1
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
Input / Output Description
-- Reserved
-- GND
-- 24V DC
Output BUSY
-- GND
Input START
Input PRG 1
Input PRG 3
-- Reserved
-- Reserved
Output READY
Output ERROR
Input REMOTE
Input ERROR-IN
Input
PRG 2
PRG-Selectbit #1
0
1
0
1
0
1
0
1
Operating Instructions DC 1200
Comment
Reserved
GND
24V DC
Dispensing procedure active
GND
Starts dispensing
Program select Bit #1
Program select Bit #3
Reserved
Reserved
Ready signal
Error signal
Remote active
External Error input
Program select Bit#2
PRG-Selectbit #2
0
0
1
1
0
0
1
1
32
PRG-Selectbit #3
0
0
0
0
1
1
1
1
