10 Technical Data

Dimensions (WxHxD)
Weight
Power supply
Operating voltage
Timer
Air inlet
Air outlet
Vacuum suck-back
Graphic display
Memory

11 Electrical connections

11.1 Foot switch

pins:

11.2 I/O-Port

type:
pins:
Supply voltage:
Do NOT apply an external supply voltage to these pins!
This can lead to a defect and damage to the device.
235 x 75 x 220 mm
ca . 1,50 kg
85 – 264 V AC 50/60 Hz
24 V DC
0,01 - 999 sec .
0 - 7 bar
0 - 2 / 4 / 6 bar (precise air regulator)
• indication of all pressures
• excellent overview of all necessary data
• 3-digits units
128 x 64 pixels
8 program memory spaces
connection between Pin 1 + 3 starts dispensing
15-pol . Sub-D female 2-doublerow
see following chart
The dispenser has an internal 24 V power supply
available at Pin 2 + 3 with max . 100 mA .
