Single Axis Foot
DE
Final Assembly
Assemble the prosthesis for fitting.
Follow the instructions for all used
components, especially regarding the
torque of components connected to
the foot pyramid.
Using a 4mm hex key, tighten the ankle
in retaining screw
derside of the foot.
To definitively finish the assembly
of the prosthesis, secure all screw
connections with medium-strength
threadlocking fluid (e.g. 242).
Material
Aluminum
Titanium
Stainless steel
Composite material
Plastics
Product Care/Cleaning/
Maintenance
If necessary, the foot components can be
cleaned with a damp cloth.
We recommend conducting a visual and
functional inspection of all moving parts
after 6 months, and of all other compo-
nents after 12 months.
EN-8
User Manual
Nm) from the un-
(7
Storage/Disposal
Store the products in their original packa-
ging in a dry place. Protect from dust,
dirt and moisture. This product does not
contain any environmentally hazardous
substances. It can be disposed of with
regular household waste.
Liability
The manufacturer recommends using
the product only under the specified
conditions and for the intended pur-
poses, as well as only using modular
components which have been certified
for the prosthesis, and to maintain the
product according to the user manual.
The manufacturer will not accept
liability for damages caused through
improper use of the components.
Warranty
The warranty period for Single Axis Feet
is 12 months.
