Single Axis Foot; Technical Data; Indication; Medical Device - Teufel Single Axis Fuß Gebrauchsanweisung

Technical Data

Weight of Foot/g
Weight Limit/kg
Foot Sizes/cm
System Height/mm
Heel Height/mm
Proximal Adapter
Category
Toe Resistances
Deflection
Bumper Densities

Indication

Activity Level: 1 – 2
1 2 3
Weight limit: 115 kg
Weight limit: The user' s adjusted body
weight may not exceed the weight limit.
Adjusted bodyweight: The sum of the
user's body weight and the weight of
loads he normally or routinely carries.
(See catalog for classification!)
The product is designed to be part of a
prosthesis for a lower limb amputee.
571 (Sz. 26, incl.
Adapter)
115
22 - 31
81.3
• Before this component is used, both
10
Pyramid Adapter
2 - 4
• Before the component is used, the user
Soft,
Medium, Firm
• Incorrect selection, adaptation, appli-
• The prosthesis and its functional
4
max. 115 kg
• If the prosthesis or any of its compo-
• All serious incidents that occur in

Single Axis Foot

Medical Device

The Single Axis Foot is a
medical device.

Safety

the component and the prosthesis it is
used for have to be individually adapted
to the user.
has to be trained in the component's
use by an experienced orthopedic
technician.
cation and/or faulty inspection of this
product may cause health damage.
components must be checked for
proper function, possible wear and tear
and potential damage by an orthopedic
technician at regular intervals.
nents have been subject to dispropor-
tionate stress (e.g. due to a fall), they
must be checked for potential damage
by an orthopedic technician before
further use.
connection with this product have to
be reported to the Wilhelm Julius Teufel
GmbH and the competent authority
of the member state in which you are
established. A "serious incident" is any
incident that caused, may have caused,
or may cause, directly or indirectly, one
of the following consequences:
a) death of a patient, user, or other
persons
ES
FR
EN
User Manual
DE
EN-3
