Survey and construction

1
6
1. Carry handle (for carrying SAFEFLEX SF)
2. Scale to adjust the height of the treadplate
3. Protection bracket
3 Installation
For ergonomic work the threadplate (4) can be complemented
with enclosed support feet (6) and by this increased in height.
For this, screw in all support feet (6) in the thread holes on the
bottom of the device until up to the limit. Afterwards, secure the
screws with lock nuts (8).
5121.0001
2
4. Treadplate
5.
6. Support feets (to increase the working height)
V1
6
Support surface for blocks, pavers
6 / 9
3
4
5
8
6
