6.3 Installing the Protective Cover and Foot Cuff
6.3.1 Installing the Foot Cuff
1) Remove the prosthetic foot from the tube adapter.
In doing so, unscrew the two set screws that are screwed in the furthest but are not opposite
each other. Mark the two set screws.
2) Pull the foot cuff over the tube adapter (see Fig. 10).
3) Install the prosthetic foot on the tube adapter (see Fig. 11).
Apply Loctite® 241 to the two set screws and screw them in.
4) Position the clips of the foot cuff on the footshell, aligning the seam to posterior.
5) Attach the clips in the footshell (see Fig. 12).
INFORMATION: When using the 1C40 C-Walk, the clips that do not engage have to be
removed.
6.3.2 Protective Cover Installation
1) Remove the crepe adhesive tape from the Protective Cover after final shortening.
2) Open or remove the closures.
3) Spread open the Protective Cover.
4) Thread the Protective Cover into the Protective Cover foot cuff from anterior (see fig. 13).
5) Apply the Protective Cover to the knee joint.
INFORMATION: The retainers of the Protective Cover have to engage on the frame ele­
ment.
6) Fasten the two closures on the back of the Protective Cover (see fig. 7 and see fig. 15).
NOTICE
Loss of stability due to inadequately installed retainers
No hold of the Protective Cover on the knee joint.
Ensure that all retainers and closures are properly engaged and/or fastened.
►

6.4 Functional Test

After assembly, the following points have to be checked:
• Does the foot cuff overlap the Protective Cover by approx. 2 cm?
• Is the function of the rotation adapter impaired?
Material may be removed from the Protective Cover to improve the functionality.
INFORMATION: If material is removed, the stability/flexibility of the Protective Cover
on the knee joint may be impaired.
7 Maintenance
► During the standard inspection of the prosthesis components, also inspect the product.

7.1 Cleaning and Care

NOTICE
Improper product care
Damage to the product due to the use of incorrect cleaning agents.
Only clean the product with a damp cloth and mild soap (e.g. 453H10=1-N Ottobock Der­
►
maClean).
1) Clean the product with a damp, soft cloth.
2) Dry the product with a soft cloth.
3) Allow to air dry in order to remove residual moisture.
