1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We wish you much joy and success in working with
your new appliance.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu-
lations and VDE regulations 0100, DIN 57113 /
VDE0113.
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device.
The operating instructions are intended to help the
user to become familiar with the machine and take
advantage of its application possibilities in accord-
ance with the recommendations.
The operating instructions contain important informa-
tion on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, cost-
ly repairs, reduce downtimes and how to increase
reliability and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regula-
tions that apply for the operation of the machine in
your country.
Keep the operating instructions package with the
machine at all times and store it in a plastic cover to
protect it from dirt and moisture. Read the instruction
manual each time before operating the machine and
carefully follow its information.
The machine can only be operated by persons who
were instructed concerning the operation of the ma-
chine and who are informed about the associated
dangers. The minimum age requirement must be
complied with.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
In addition to the safety instructions contained in this
operating manual and the specific regulations of your
country, the technical rules generally accepted for the
operation of machines of the same type must be ob-
served.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
2. Device description (Fig. 1a, 1b)
1. Handle/hand grip
2. Front handle
3. Plunge-cut trigger
4. On/off switch
5. Base plate
6. Adjustment screw for depth of cut
7. Scale for depth of cut
8. Mitre adjustment screw
9. Mitre square
10. 90-degree adjustment screw
11. Saw blade
12. Suction nozzle
13. Adjustment screw for guide rail
14. Shaft locking mechanism
15. Splitter guard
General information
• After unpacking, check all parts for possible trans-
portation damages. In the event of complaints, in-
form the supplier immediately. Any complaints
made after this time will not be accepted.
• The shipment is to be checked for completeness
upon receipt.
• Read through the manual carefully in order to
make yourself familiar in dealing with the device
before using it for the first time.
• Only use original equipment regarding accesso-
ries, as well as consumable items and spare parts.
Spare parts can be obtained from your special-
ized dealer. When ordering, please specify our
part numbers, as well as type and construction
year of the device.
m Important!
The equipment and packaging material are not toys.
Do not let children play with plastic bags, foils or
small parts. There is a danger of swallowing or suf-
focating!
