Technical Data; Before Starting The Equipment - Scheppach HM135B Originalbetriebsanleitung

• The laser may not be replaced with a different type
of laser.
• Repairs of the laser may only be carried out by the
laser manufacturer or an authorised representa-
tive.

6. Technical data

AC motor
Power
Operating mode
Idle speed n
0
Carbide saw blade
Number of teeth
Swivel range
Mitre cut
Saw width at 90°
Saw width at 45°
Saw width at 2 x 45°
right (double mitre cut)
Saw width at 2 x 45° left
(double mitre cut)
Protection class
Weight
Laser class
Wavelength of laser
Laser output
* S6, continuous operation periodic duty.
Identical duty cycles with a period at load fol-
lowed by a period at no load. Running time 5
minutes; duty cycle is 40% of the running time.
The work piece must have a minimum height of
3mm and a minimum width of 10 mm.
Make sure that the workpiece is always secured
with the clamping device.
Noise and vibration
Total vibration values determined in accordance with
EN 61029.
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing.
Total vibration values (vector sum - three directions)
determined in accordance with EN 61029.
230 - 240 V~ 50Hz
2000 Watt
S6 40%*
3800 min
-1
ø 305 x ø 30 x 3 mm
24
-45° / 0°/ +45°
0° bis 45° to the left
330 x 105 mm
230 x 60 mm
230 x 35 mm
230 x 60 mm
II
20,8 kg
2
650 nm
≤ 1 mW
95 dB(A)
3 dB
108 dB(A)
3 dB
Residual risks
The machine has been built according to the
state of the art and the recognised technical
safety requirements. However, individual residu-
al risks can arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the „safety in-
structions" and the „Proper use" are observed
along with the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the ma-
chine in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be fixed between the clamps.
• Avoid accidental starting of the machine: the op-
erating button may not be pressed when inserting
the plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your mitre saw provides optimal per-
formance.
• Hands may never enter the processing zone when
the machine is in operation. Release the handle
button and switch off the machine prior to any op-
erations.

7. Before starting the equipment

• The equipment must be set up where it can stand
securely, i.e. it should be bolted to a workbench,
a universal base frame or similar. Use the holes in
the frame of the machine.
• All covers and safety devices have to be properly
fitted before the equipment is switched on.
• It must be possible for the blade to run freely.
• When working with wood that has been processed
before, watch out for foreign bodies such as nails
or screws, etc.
• Before you press the ON/OFF switch check that
the saw blade is fitted correctly. Moving parts must
run smoothly.
• Before you connect the equipment to the power
supply make sure the data on the rating plate are
dentical to the mains data.
GB 25
