Protect yourself and you environment from ac-
cidents using suitable precautionary measures!
• Do not look directly into the laser beam with un-
protected eyes.
Never look into the path of the beam.
•
Never point the laser beam towards reflecting sur-
•
faces and persons or animals. Even a laser beam
with a low output can cause damage to the eyes.
• Caution - methods other than those specified here
can result in dangerous radiation exposure.
Never open the laser module. Unexpected expo-
•
sure to the beam can occur.
If the mitre saw is not used for an extended period
•
of time, the batteries should be removed.
The laser may not be replaced with a different type
•
of laser.
Repairs of the laser may only be carried out by the
•
laser manufacturer or an authorised representative.
Safety instructions for handling batteries
Always make sure that the batteries are inserted
1
with the correct polarity (+ and –), as indicated
on the battery.
Do not short-circuit batteries.
2
Do not charge non-rechargeable batteries.
3
Do not overcharge batteries!
4
Do not mix old and new batteries or batteries
5
of different types or manufacturers! Replace an
entire set of batteries at the same time.
Immediately remove used batteries from the de-
6
vice and dispose of them properly!
Do not allow batteries to heat up!
7
Do not weld or solder directly on batteries!
8
Do not dismantle batteries!
9
Do not allow batteries to deform!
10
11 Do not throw batteries into fire!
Keep batteries out of the reach of children.
12
Do not allow children to replace batteries without
13
supervision!
Do not keep batteries near fire, ovens or other
14
sources of heat. Do not use batteries in direct
sunlight or store them in vehicles in hot weather.
15 Keep unused batteries in the original packaging
and keep them away from metal objects. Do not
mix unpacked batteries or toss them together!
This can lead to a short-circuit of the battery
and thus damage, burns or even the risk of fire.
Remove batteries from the equipment when it
16
will not be used for an extended period of time,
unless it is for emergencies!
NEVER handle batteries that have leaked with-
17
out appropriate protection. If the leaked fluid
comes into contact with your skin, the skin in
this area should be rinsed off under running wa-
ter immediately. Always prevent the fluid from
coming into contact with the eyes and mouth.
In the event of contact, please seek immediate
medical attention.
Clean the battery contacts and corresponding
18
contacts in the device prior to inserting the bat-
teries:
26 GB

6. Technical data

AC motor
Power
Operating mode
Idle speed n
0
Carbide saw blade
Number of teeth
Swivel range
Mitre cut
Saw width at 90°
Saw width at 45°
Saw width at 2 x 45°
(double mitre cut)
Protection class
Weight
Laser class
Wavelength of laser
Laser output
Laser module power
supply
* S6, continuous operation periodic duty.
Identical duty cycles with a period at load fol-
lowed by a period at no load. Running time 5
minutes; duty cycle is 20% of the running time.
The work piece must have a minimum height of
3mm and a minimum width of 10 mm.
Make sure that the workpiece is always secured
with the clamping device.
Noise and vibration
Total vibration values determined in accordance with
EN
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing.
Total vibration values (vector sum - three directions)
determined in accordance with EN 61029.
Residual risks
The machine has been built according to the
state of the art and the recognised technical
safety requirements. However, individual residu-
al risks can arise during operation.
Health hazard due to electrical power, with the use
•
of improper electrical connection cables.
230 - 240 V~ 50Hz
2150 Watt
S6 20% 5 Min*
3200 / 4500 min
-1
ø 255 x ø 30 x 2,8 mm
48
-45° / 0°/ +45°
0° bis 45° to the left
305 x 90 mm
215 x 90 mm
215 x 47 mm
II
15,5 kg
2
650 nm
≤ 1 mW
3 x LR44
button cell
61029.
95.23 dB(A)
3 dB
108.23 dB(A)
3 dB
