• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the „safety in-
structions" and the „Proper use" are observed
along with the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the ma-
chine in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be fixed between the clamps.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your machine provides optimal perfor-
mance.
• Hands may never enter the processing zone when
the machine is in operation.
• Release the handle button and switch off the ma-
chine prior to any operations.
Warning! This electric tool generates an electromag-
netic field during operation. This field can impair ac-
tive or passive medical implants under certain condi-
tions. In order to prevent the risk of serious or deadly
injuries, we recommend that persons with medical
implants consult with their physician and the manu-
facturer of the medical implant prior to operating the
electric tool.

6. Technical data

AC motor ....................................... 220−240 V~ 50Hz
Power S1 ....................................................2000 Watt
Idle speed n ..............................................4500 min
0
Carbide saw blade .................... ø 255 x ø 30 x 3 mm
Number of teeth...................................................... 60
Maximum tooth width of saw blade ....................3 mm
Swivel range ....................................... −45° / 0°/ +45°
Mitre cut ............................... from 0° to 45° to the left
Saw width at 90° ................................... 340 x 90 mm
Saw width at 45°.....................................240 x 90 mm
Saw width at 2 x 45°
(double mitre cut) ...................................240 x 45 mm
Protection class ................................................... II /
Weight ....................................................... ca. 14,3 kg
Laser class ................................................................2
Wavelength of laser ........................................ 650 nm
Laser output ................................................... < 1 mW
www.scheppach.com /
-1
service@scheppach.com /
The work piece must have a minimum height of
3 mm and a minimum width of 10 mm.
Make sure that the workpiece is always secured
with the clamping device.
Noise
Total noise values determined in accordance with EN
62841.
Sound pressure level L ........................96.5 dB(A)
pA
Uncertainty K ..................................................3 dB
pA
Sound power level L ..........................109.5 dB(A)
WA
Uncertainty K .................................................3 dB
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing
The above-mentioned noise emission values were
measured in accordance with a standardised test
procedure and can be used to compare one power
tool with another.
The above-mentioned noise emission values can
also be used for the preliminary assessment of ex-
posure.
Warning:
• The noise emissions during the actual use of the
power tool may differ from the above-mentioned
values depending on the power tool being used,
in particular on the type of workpiece being pro-
cessed.
• Try to keep emissions as low as possible. For ex-
ample: Limit your working time. In this regard, all
the operational cycle phases must be taken into
consideration (such as the times when the tool is
switched off or running idle).

7. Before starting the equipment

• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, store the packaging until the warranty
period has expired.
DANGER
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, film and small parts! There is a risk of
swallowing and suffocation!
• The equipment must be set up where it can stand
securely. Secure the machine on a workbench or a
base frame with 4 screws (not included in delivery)
using the holes on the fixed saw table (15).
