Configuration Example
Out of the four possible vibrating forks the first and the third ones are being used. Out
of the eight possible sensors the second and the third ones are being used.
4s are set as settling time of the vibrating forks.
The list of the used modules should be structured as follows:
Pos.
1
OUT_D
2
EMPTY_MODULE
3
OUT_D
4
EMPTY_MODULE
5
EMPTY_MODULE
6
OUT_D
7
OUT_D
8 ... 12
EMPTY_MODULE
A possible parameterization string could be: 00 00 00 53 01 02 01 03 02 01
Meaning: the first three bytes are always 0, afterwards there is the configurating byte
for the vibrating fork 1, which contains the settling time settings the oft the vibrating
forks (53), vibrating fork 2 (01, not used, i. e. deactivated), vibrating fork 3 (02), vibra-
ting fork 4 (01, not used, i. e. deactivated), Sensor 1 (03, not used, i. e. deactivated),
Sensor 2 (02) and Sensor 3 (01). At maximum, 5 more bytes could follow for the sen-
sors 4 to 8.
During the cyclic user data exchange the following eight bytes are transferred:
1. Byte
2. Byte
Data
Status
Fork1
Fork1
12
Subject to reasonable modifications due to technical advances.
Pepperl+Fuchs Group • Tel.: Germany +49-621-776-0 • USA +1-330-4253555 • Singapore +65-67-799091 • Internet www.pepperl-fuchs.com
Module
Vibrating fork 1
Vibrating fork 2 is not used
Vibrating fork 3
Vibrating fork 4 is not used
Sensor 1 is not used
Sensor 2
Sensor 3
Sensor 4 ... 8 is not used
3. Byte
4. Byte
Data
Status
Fork3
Fork3
Instruction Manual
FD0-BI-Ex12.PA
Use
5. Byte
6. Byte
7. Byte
Data
Status
Data
Sens2
Sens2
Sens3
Copyright Pepperl+Fuchs, Printed in Germany
8. Byte
Status
Sens3
