Connections, Clamping Areas, Covers
The Sensor Interface FD0-BI-Ex12.PA has got two clamping areas which are protec-
ted by screwed lids with sealings. The smaller lid 1 covers the clamping area of the
PROFIBUS PA cable. The larger lid 2 covers the clamping area for the vibrating forks
and the sensors.
Terminal Assignment
Right clamp space under the lid 1 (PROFIBUS PA communication):
Terminal
+
S
-
6
Subject to reasonable modifications due to technical advances.
Pepperl+Fuchs Group • Tel.: Germany +49-621-776-0 • USA +1-330-4253555 • Singapore +65-67-799091 • Internet www.pepperl-fuchs.com
Signal
PROFIBUS PA +
Shield
PROFIBUS PA -
Instruction Manual
Explanation
PROFIBUS PA bus cable +
Shield of the bus cable
PROFIBUS PA bus cable -
