6. Plug in power supply.
7. Insert battery into Scan Room Unit.
8. Ensure that the Control Room Unit is powered On and verify that the
Integrated Continuous Battery Charger system Status Indicator on
Control Room Unit Display indicates that the Continuous Battery Charger
is operational.
Circular Connector Hole (use connector plate)
Use the Circular Connector Hole when the penetration panel does not have
free connector holes to mount a connector.
1. Outside the Procedure Room, position the power supply on the floor by
an AC power plug so that the power cord can reach the plug and that it is
no more than 20 ft. (6.1m) from the penetration panel.
2. Remove the protective tape from the dual lock on the bottom of the power
supply and stick to a clean surface.
3. Drill a 1.375" (3.5 cm) hole in the penetration panel in accordance with
MR room safety practices.
4. Attach the iCBC filtered cable to the connector plate by removing and
reattaching the standoffs to the connector.
5. Using non-ferrous tools, mount the connector plate with cable attached
through the hole (cable located inside the equipment room).
NOTE: There are "wings" on the adapter plate that swing open
as the screws are tightened. This holds the plate onto
the penetration panel.
6. Apply copper tape around the connector plate to seal any gaps between
the plate and the hole.
7. Route 50 ft (15.2 m) cable from the penetration panel to the Scan Room
Unit.
8. Connect cable into Scan Room Unit.
9. Plug in Power Supply
10. Insert the battery into the Scan Room Unit.
11. Ensure that the Control Room Unit is powered On and verify that the
Integrated Continuous Battery Charger system Status Indicator on
Control Room Unit Display indicates that the Continuous Battery Charger
is operational.
