SET
KEELDEPTH
Do not press push-button. The currently set keel depth (here basic
setting: 1.0) appears.
1,0
m
Keeping the push-button depressed increases the keel depth. The
alteration speed of the keel depth increases after 3 seconds.
The alteration direction can be changed by briefly pressing the push-
button. This is indicated via a reversed arrow.
The adjustment range of the keel depth varies from 0.1m (0.4ft) to 9.7m
(32ft). The keel depth is reset to 0.1 m (0.4 ft) after reaching 9.7m (32ft).
If the push-button is not pressed for approx. 5 seconds, the set keel
depth is recorded and the subsequent display automatically appears.
3.4.10 Adjustment of depth indicator damping (Depth Damping)
Indicator damping can be set in 4 levels (OFF, LOW, MIDDLE, HIGH)
according to the condition of the sea bed (rocky, muddy) and the water
conditions (fresh water, salt water, brackwater).
Adjust the sensitivity as follows:
DEPTH Damping DEPTH Damping
Press button
LOW MIDDLE
In the diagrammed example, the sensitivity is changed from low LOW to
MIDDLE.
