Product description

Control unit cover
Wall/pillar
mounting
bracket

Space requirements

104,70 mm

Field of application

This automatic control system has been designed to motorise residential double door
gates for a detached house.
Dimensions and weight of the gate leaves
Max. weight per leaf (P)
Max height per gate leaf (H)
Min./Max. weight per leaf (L)
The type of gate (solid/open-worked) and the weather conditions (presence of strong
winds), may reduce these maximum values (see table below).
7
EN - EXAVIA installation and operating guide - SOMFY
Bracket screw
Cover screw
Cylinder bracket pin
105,05 mm
164,49 mm
30,00 mm
177,11 mm
250 kg
2 m
1.25/2.5 m
Cylinder
24V
Cylinder stop
88,1 mm
149,59 mm
187 mm
72 mm
Bracket
Sealing strip
Control electronics
Cable clamp
Cable clamp bolt
Catch
Gate leaf mounting
bracket
Unlocking
mechanism screw
780,9 mm
208 mm
Unlocking
mechanism
70,5 mm
