Dimensions
Power
A B
[kW]
0.9 and 1.2 466 100
1.5 (3 phase) 466 100
1.5 (1 phase) 471 100
2.6 522 100
3.1 and 4.0 562 100
Power
Z4 Z6
[kW]
0.9 and 1.2 118 424
1.5 (3 phase) 118 424
1.5 (1 phase) 118 424
2.6 118 460
3.1 and 4.0 118 460
Weights
Pump type
SEG.40.09.2.1.502
SEG.40.09.2.50B/C
SEG.40.12.2.1.502
SEG.40.12.2.50B
SEG.40.12.2.50C
SEG.40.15.2.1.502
SEG.40.15.2.50B
SEG.40.15.2.50C
SEG.40.26.2.50B/C
SEG.40.31.2.50B/C
SEG.40.40.2.50B/C
C D DN2 E
255 99 DN 40 154
255 99 DN4 0 154
255 99 DN 40 154
292 119 DN 40 173
292 119 DN 40 173
Z6a Z7 Z9 Z10a
365 374 70 3/4"-1"
365 374 70 3/4"-1"
365 374 70 3/4"-1"
365 410 70 -
365 410 70 -
Weight
[kg]
40
39
40
40
39
53
40
39
62
70
40
F G1 H I M
216 214 71 123 134
216 214 71 123 134
216 214 71 123 134
256 215 60 143 134
256 214 60 144 134
Z11 Z12a Z15
546 68 90
546 68 90
551 68 90
614 80 90
652 80 90
N O V1 Y2
100 510 116
100 510 116
min.
100 515 116
600
100 582 115
100 622 115
Z16 Z18 Z19 ZDN1
221 271 120 Rp 11/2
221 271 120 Rp 11/2
221 271 120 Rp 11/2
221 271 120 Rp 11/2
221 271 120 Rp 11/2
Z3
115
115
115
115
115
29
