KEB COMBIVERT F4-F Lift Betriebsanleitung Seite 90

8. Parameter Description
ASM-Rated Motor Speed
GB
ASM-Rated Motor Current
ASM-Rated Motor Frequency
ASM-Rated Motor Voltage
ASM-Power Factor cos ϕ ϕ ϕ ϕ ϕ
Field Weakening Speed
GB 28
Unit:
Value range :
Factory setting:
Adjustment value:
You may not enter the motor-synchronous speed
(e.g. 1500 rpm for a 4 pole motor). Ask the manufacturer
for the motor rated speed if you cannot find it on the
name plate.
Unit:
Value range:
Factory setting:
Adjustment value:
Unit:
Value range:
Factory setting :
Adjustment value:
Unit:
Value range:
Factory setting:
Adjustment value:
Unit:
Value range:
Factory setting:
Adjustment value:
Unit:
Value range:
Factory setting:
Adjustment value:
rpm
100...6000 rpm
1440 rpm
in accordance with the motor name plate
ampere
1,0...1,1 * Inverter rated current
8,0 A
in accordance with the motor name plate
hertz
20...100 Hz
50 Hz
in accordance with the motor name plate
volt
1...650 V
400 V
in accordance with the motor name plate
1
0,01...1,00
0,86
in accordance with the motor name plate
rpm
0,0...6000,0 rpm
1200,0 rpm
approx. 80% of the synchronous speed
