Para. Name
ru.00 Display Inverter Status
ru.02 Actual Torque Display
ru.04 Set Speed Display
ru.08 Peak Inverter Utilization
ru.09 Apparent Current
ru.10 Active Current
ru.11 Actual DC Voltage
ru.12 Peak DC Voltage
ru.14 X2 Input Terminal Status
ru.15 X2 Output Terminal Status
ru.18 Actual Parameter Set
ru.20 Speed Reference Display
ru.22 Ref1 Display
ru.23 Ref2 Display
ru.24 OL Counter Display
ru.25 Peak Apparent Current
ru.29 Heat Sink Temperature
ru.31 Power On Counter
ru.32 Modulation On Counter
In.00 Inverter Type Display
In.01 Rated Inverter Current
In.06 Configfile Number
In.07 Serial Number High
In.08 Serial Number Low
In.09 Serial Number Order No. High
In.10 Serial Number Order No. Low
In.11 Customer Number High
In.12 Customer Number Low
In.40 Last Error
In.41 Error Counter OC
In.42 Error Counter OL
In.43 Error Counter OP
In.44 Error Counter OH
In.45 Error Counter WD
In.54 Software ID Version DSP
In.55 Software Date DSP
In.56 Feedback System Channel 1
In.57 Feedback System Channel 2
10. Supplement
Address E R Res. Lower
Limit
2000 R Table
2002 R 0,1
2004 R 0,5
2008 0,1
2009 R 0,1
200A R 0,1
200B R 1
200C R 1
200E R Table
200F R Table
2012 R Table
2014 R 0,5
2016 R 0,1
2016 R 0,1
2018 R 1
2019 R 0,1
201D R 1
201F R 1
2020 R 1
2C00 Table
2C01 0,1
2C06 R 1
2C07 1 0
2C08 1 0
2C09 1 0
2C0A 1 0
2C0B 1 0
2C0C 1 0
2C28 1 0
2C29 1 0
2C2A 1 0
2C2B 1 0
2C2C 1 0
2C2D 1 0
2C36 R
2C37 R
2C38 R
2C39 R
ANTRIEBSTECHNIK
Upper Default Unit
Limit
-
Nm
rpm
%
A
A
V
V
GB
rpm
%
%
-
A
°C
h
h
A
65535 0
65535 0
65535 0
65535 0
65535 0
65535 0
63 0
255 0
255 0
255 0
255 0
255 0
GB 63
