4.2.5 Drive Curve Door Drive

v
LF.46
X2.4
X2.6
X2.3
X2.1
X2.7
Operating Points
What happens when? Description of the operating points of the door drive.
1: The acceleration process starts after the setpoint input is activated (X2.7 = 1).
Condition:
2: When the setpoint for (X2.7) is removed deceleration begins.
LF.50
LF.51
LF.50
1
Door drive is active (X2.6)
Control release is active (X2.1)
Direction of rotation (X2.3 / X2.4) is preset
4. Drive Curves
LF.54
LF.53
LF.54
2
