Terminal
X2.5 Control Mode
X2.6 Door Drive
Active
X2.7 Door Drive
Setpoint Input
X3.1 Contactor Control The input X3.1 checks to see if the main contactor and the braking
X3.2 Correction
Speed V
B
X3.3 Crawl Speed, V
X3.4 Rated Speed, V
X3.5 Inspection Speed, When the input is assigned +24 V the inspection speed is activated.
V
I
X3.6 1st Intermediate
Speed, V
1
X3.7 2nd Intermediate
Speed, V
2
Motor Temperature De- Terminal motor-PTC !
tector Terminals OH/OH
Description
In activating the input you can switch from open loop operation to speed
controlled operation.
! only when LF.30 = 1 !
In addition to the main drive the inverter can also start a door drive. The
activation of the input causes the switching from the main drive to door
drive. For settings, functions and drive curves of the door drive
see pages GB 14 - GB 15 !
When the input is set with +24 V the set value of the door drive is activated.
The set speed of the door drive is preset in parameter LF.46. For
settings, functions and drive curves of the door drive see page
GB 14 - GB 15 !
contactor are released. The input must be activated when a drive
command is entered. If the input is not set, the display "S.Co" (Error,
contactor open) appears in parameter LF.98. The power modules are
blocked.
The contactor control can be simulated, by bridging input X3.1 with
output X2.9.
When the input is assigned +24 V the correction speed is activated.
When the input is assigned +24 V the crawl speed is activated.
E
When the input is assigned +24 V the rated speed is activated.
N
When the input is assigned +24 V the 1st intermediate speed is activated.
When the input is assigned +24 V the 2nd intermediate speed is activated.
see also page GB 11, terminal X3.23
3. Inputs/Outputs
! also see parameter LF.40 !
! also see parameter LF.41 !
! also see parameter LF.42 !
! also see parameter LF.43 !
! also see parameter LF.44 !
! also see parameter LF.45 !
ANTRIEBSTECHNIK
GB
GB 9
