Set-Up Instructions - Integra MAYFIELD Infinity XR2 Gebrauchsanleitung

The MAYFIELD Infinity XR2 Base Unit (A2079) includes:
(1) MAYFIELD XR2 Base Unit
(2) MAYFIELD XR2 Link Arm Assembly 437A2222
(3) MAYFIELD XR2 Swivel Adaptor 437A2400

Set-up Instructions:

1. Yoke (Yellow tip to Link Arm Locking Knob with Yellow Sleeve
2. Link Arm Assembly
3. Swivel Adaptor (Blue tip to Link Arm Knob with Blue Sleeve)
Downloaded from www.Manualslib.com
1
Figure 2 Base Unit Set-up
