Inspection
Always inspect instruments before and after use. If a component appears damaged and/or does
not seem to function properly, do not use the device and immediately send the instrument to
Integra LifeSciences, Cincinnati, Ohio or an authorized Integra repair center for evaluation, repair
or replacement.
8
9
1. Skull Clamp/Headrest Locking Knob
2. Swivel Adaptor
3. Link Arm Locking Knobs
4. Yoke
5. Crossbar
6. Base Handle
7. Side Rail Bracket
8. Locking Lever
9. Base Handle Adjustment Knob
10. Auxilliary Side Rail
11. Side Rail Bracket Locking Knob
Downloaded from www.Manualslib.com
1
5
4
Figure 1 A2079 Infinity XR2 Base Unit Components
manuals search engine
2
3
3
Page 1
10
7
11
6
