4. Return the Adjustment Knob to its locked position by releasing it and rotating it to the
nearest seated locking position.
5. Test the operation of the handle. With the Locking Lever fully opened, the Locking Bracket
should rotate freely. With the Locking Lever closed, the Locking Bracket should not rotate.
NOTE: Once the desired setting is achieved confirm the Adjustment Knob is in the locked,
seated position.
It is possible to adjust the handle to the point that the Locking Lever requires
excessive force to close. Do not exert excessive force as this may result in
damage to the device if the lever is forced closed.
Downloaded from www.Manualslib.com
Adjustment Knob
Figure 9 Adjustment Knob in Locked Position
manuals search engine
Adjustment Knob Retracted
to the Locked Position
CAUTION!
Page 14
