2. Grasp the Adjustment Knob and pull it away from the Locking Bracket to unlock.
3. Holding the Adjustment Knob in its unlocked position, rotate it in the desired direction to
adjust tension. Clockwise (+ plus) direction to increase tension, or Counterclockwise
(- minus) direction to decrease tension.
Downloaded from www.Manualslib.com
Adjustment Knob
Decrease Locking
Lever Tension
manuals search engine
Adjustment Knob Pulled to
the Unlocked Position
Figure 8 Adjustment Knob
Page 13
Increase Locking
Lever Tension
