– In the union nut of the gas filter (Figure 3 - 5), place a sealing
ring (Figure 3 - 4) on the collar.
– Screw the MonoControl CS T (Figure 3 - 3) and gas filter
(Figure 3 - 5) together finger tight.
– In the small union nut of the adapter (Figure 3 - 7), place a
sealing ring (Figure 3 - 6) on the collar.
– Screw the gas filter (Figure 3 - 5) and adapter together
finger tight.

Install the unit in the fitting box

1
2
Figure 5
– Make sure that the large union nut of the adapter (Figure 3 - 7)
contains the white plastic seal.
– Place the assembled unit in the fitting box (Figure 5 - 4)
and screw the thread connection of the adapter on to the
withdrawal valve (Figure 5 - 3) of the tank finger tight (left-
hand thread).
– Use a spanner (AF 30) to tighten the union nut on the
adapter. Use a suitable spanner to brace against the with-
drawal valve.
16 EN
– Align the gas pressure regulator and the gas filter so that
both are vertical to the floor. (Figure 6)
3 4
Figure 6
If the crash sensor is not vertical, this may result in
false triggering during normal driving and/or the device
not triggering in the event of a crash. Besides, it cannot be
properly reset after it has triggered.
