Installation Instructions - Truma MonoControl CS T Set Einbauanweisung

Installation instructions

Only competent and trained staff (experts) are permitted
to install and repair the Truma product and to carry out the
function test, at the same time observing the installation and
operating instructions and the currently recognised technical
regulations. Experts are persons who, based on their special-
ist instruction and training, their knowledge and experience
with Truma products and the relevant standards, can carry out
the necessary work properly and identify potential hazards.
Disregarding installation instructions or incorrect
installation can put people in danger and cause
damage to property.
– It must be ensured that the MonoControl CS T gas pressure
regulator and the gas filter are not subjected to stresses and
are installed and fastened in such a way that no damaging
vibrations can be transmitted to the fittings.
– Vibration in the vehicle chassis is transmitted to the gas
tank. If the gas tank is not properly attached, vibration
may be transmitted to the extent that the crash sensor is
triggered or fittings are damaged.
– If necessary, additional measures must be taken to rule out
negative effects of potential vibration on the fittings, gas
pipes and gas pipe connections.
14 EN
– Particular attention must be paid that the gas pipes are laid
so that they can absorb or decouple movement between
the tank and the chassis, which, for example, is caused by
vibration of the LP gas tank (particularly in the case of tanks
that have a large capacity or that are attached to the side).
– Among other things, the following standards must be taken
into consideration:
DIN EN 1949
- Dynamic load
- Pipe connections
- Fixing
- Installation of LP gas tanks
DIN EN 12979, Annex B
- Annex B1 Tank attachment
- Annex B2 Vehicle frame
– In the case of caravans and motor homes with 30 mbar
consumer appliances, the maximum pressure loss ΔP of the
downstream installation to the appliance must not exceed
5 mbar (ΔP5).
