6.2 Basic D 40, Ø 200 – 520 mm (Ø 7.87" – 33.07")
Fixings for precision boring tool
537digital and 337 and counter
weight (not included
in the equipment supplied)
Serrated Cap screw ②
slide ①
Part No. Part No.
315186
349021
349022 315186
349023 315186
315186
349024
24
Clamping
Key bolt ③
(torque) Part No.
115669
s10/C (55 Nm)
s10/C (55 Nm) 115669
s10/C (55 Nm) 115669
115669
s10/C (55 Nm)
Cap screw ④
Key
Part No. (torque)
115118
s8/B (35 Nm)
115118 s8/B (35 Nm)
115118 s8/B (35 Nm)
115118
s8/B (35 Nm)
Ø 200 – 520 mm
(Ø 7.87" — 20.47")
Thread pin ⑤
Part No. Key
349010
s4/F
349011 s4/F
349012 s4/F
349013
s4/F
