6.10 Fastening screws for the most common indexable inserts
Insert Countersunk
form screw ①
Part No.
20 115535
115676
21
101 115676
103 115673
215149
104
105 215149
115673
112
113 215149
114 215149
115676
161
163 115673
215392
304

6.11 Service keys

Service keys / Type
s4/F
s4/B
s6/B
s8/B
s10/C
s14/C
Service keys, Torx / Typ
T 7/H
T 8/H
T 15/H
T 20/H
Torque screwdriver, Torx
(fixed torque) / Type
T 7/H (0.9 Nm) (7.97 in.lbs.)
T 8/H (1.2 Nm) (10.62 in.lbs.)
T 15/H (3.0 Nm) (26.55 in.lbs.)
T 20/H (5.0 Nm) (44.25 in.lbs.)
Service key,
torx
(torque) Nm in.lbs.
T 7/H 0.9 7.97
T 8/H 1.2 10.62
T 8/H 1.2 10.62
T 15/H 3.0 25.55
T 20/H 5.0 44.25
T 20/H 5.0 44.25
T 15/H 3.0 25.55
T 20/H 5.0 44.25
T 20/H 5.0 44.25
T 8/H 1.2 10.62
T 15/H 3.0 25.55
T 20/H 5.0 44.25
Part No.
315265
115576
115578
115579
077106
023195
Part No.
115591
115590
115664
215150
Part No.
115508
415514
415510
415543
Refer to Catalog 90200 for additional information
regarding indexable inserts and spare parts.
Type F
(Ball head)
Type B
Type H
Type H
(fixed torque)
English
①
Type C
29
