6.3 Eco D 60, Ø 465 – 1020 mm (Ø 18.31" – 40.16")
Basic Cap screw ⑧ Clamping Cap screw ⑩ Disc ⑪
slide ⑦ Part No.
Key
Part No. (torque)
077128
349005
s14/C (65 Nm)
077128
349006
s14/C (65 Nm)
65 Nm = 575.30 in.lbs.
* = Alu-Line,
** = version steel · Part No. for ⑫ incl. ⑬ and ⑭ .
Measuring pin
(only for boring range larger than 465 – 1020 mm, 18.31" – 40.16")
⑬ ⑫
bolt ⑨ Part No.
Key
Part No. (torque)
115771
415181
s10/C (55 Nm)
115771
415181
s10/C (55 Nm)
55 Nm = 486.79 in.lbs.
Serrated
slide ⑫
Part No. Part No.
349015*
115737
349014**
349015*
115737
349014**
Measuring pin
English
Clamping Cap screw ⑭
bolt ⑬ Part No.
Key
Part No. (torque)
115118
115669
s8/B (35 Nm)
115118
115669
s8/B (35 Nm)
35 Nm = 309.78 in.lbs.
Part No.
349119
25
