6.4 Flex D 60, Ø 500 – 3255 mm (Ø 19.69" – 128.15")
Fixings for precision
boring tool 537digital
and 337 and counter
weight (not included
in the equipment
supplied)
⑥
④
⑤
Basic Cap screw ②
slide① Part No.
Key
Part No. (torque)
115736
349031
s14/C (65 Nm)
415913
349032
s14/C (65 Nm)
215509
349033
s14/C (65 Nm)
415636
349034
s14/C (65 Nm)
65 Nm = 575.3 in.lbs.
Serrated Clamping
slide ⑦ bolt
⑧
Part No. Part No.
349035 349202
349036 415181
349037 415181
349038 415181
Cooling lubricant pipes: on request · Adaptor ⑪ with fixing screws.
26
Disc
③
Part No.
068168
068168
068168
068168
Cap screw ⑨ Disc ⑩
Part No.
Key
(torque) Part No.
315186
115737
s10/C (55 Nm)
077110
115737
s10/C (55 Nm)
315403
115737
s10/C (55 Nm)
315415
115737
s10/C (55 Nm)
55 Nm = 486.79 in.lbs.
⑬
⑫
⑪
⑨
② ③
Injector ④ Countersunk screw ⑤ Thread pin ⑥
Part No.
Key
Part No. (torque)
415898
349201
s6/B (20 Nm)
415898
349201
s6/B (20 Nm)
415898
349201
s6/B (20 Nm)
415898
349201
s6/B (20 Nm)
20 Nm = 177 in.lbs.
Adaptor
⑪
Part No.
349043
349043
349043
349043
English
⑩ ⑧
⑦
Part No.
Key
(torque)
–
115773
s6/B (10 Nm)
115773
s6/B (10 Nm)
–
10 Nm = 88.5 in.lbs.
Clamping Cap screw ⑬
bolt ⑫
Part No.
Key
Part No. (torque)
115307
115669
s8/B (35 Nm)
115307
115669
s8/B (35 Nm)
115307
115669
s8/B (35 Nm)
115307
115669
s8/B (35 Nm)
35 Nm = 309.78 in.lbs.
①
