To remove the machine from the pallet connect to it by means of the lifting bracket 1 provided, as
shown in fig. 2.
This lifting point must be used whenever you need to change the installation position of the ma-
chine. Do not attempt to move the machine until it has been disconnected from the electricity and
compressed air supply systems.
WARNING
The installation site must be chosen in strict compliance with the relevant regulations regarding
Safety in the workplace.
ImPORTANT: for correct, safe use of the equipment, users must ensure a lighting level of at least
300 lux in the place of use.
CAUTION
The installation of the machine must be performed in a dry area which must be protected
from adverse weather conditions.
Install the tyre changer in the chosen work position, complying with the minimum clearances shown
in fig. 3, adjust the height of the bead breaking support foot so that the machine is correctly posi-
tioned on the flooring.
Place the machine so that the plug-socket combination is easily accessible.
The machine must be placed on a horizontal surface, preferably concrete or tiled floor. Do not install
on unstable or damaged surfaces.
The surface on which the machine rests must withstand the loads transmitted during operation. The
surface must have a load-carrying capacity of at least 500 kg/m2.
Adjust the stabilization foot 33 (fig 3a)
- Relative humidity 50% (temp. 40°C) ÷ 90% (temp. 20°C) without condensation.
- Temperature 5°C ÷ 40°C.
INSTALLATION OF THE WHEEL LIFT (optional)
Fix the wheel lift platform on the rod using the pin and the seeger. Then fix the stabilization rod with
the screw and the relative nut and washer (Fig.3a). Assemble the grease-holder carter using the
on-purpose screws.

ELECTRICAL AND PNEUmATIC CONNECTIONS

WARNING
All operations required for the electrical connections of the equipment must be carried out
exclusively by a qualified electrician.
Before connecting the air supply system, make sure the machine is set up as in fig. 4:
pedal 13 totally downwards, column forward.
32

HOISTING/HANDLING

INSTALLATION CLEARANCES

Ambient working conditions
