3.5.2 Particulars of the inputs
Working and options
The working of the control panel input depends on the set-
ting of function no. 52 at the installer's level. Refer to the table
in section 3.5.3.
The working of the unit input depends on the setting of func-
tion no. 60 at the installer's level. Refer to the table in
section 3.5.4.
Intervening at the user's level
In general, you cannot stop the effect of an input signal at the
user's level. This does not apply for value 0 in function no. 52,
nor for value 71 in function no. 60 (see there).
However, you can set the unit to the pause mode at any time
(see section 3.1.2): the unit will then not respond to input sig-
nals. This does not apply for value 1 in function no. 52 (see
there).
Release delay
On release of the signal, you can make the effect of an input
signal continue for some time (release delay). You set the
length of the delay using function no. 76 at the installer's level
(see section 3.3.2).
The release delay works only in the unit input.
Multiple units operated from one single control panel
In general, the unit input has a global effect: one signal to one
unit has the same effect in all units connected to the control
panel. This does not apply for values 1 and 51 in function no.
60 (see there).
The control panel input has always a global effect.
