Introduction
The D-RTK is a GPS and barometer system specially designed to provide centimeter-level positioning accuracy
for the DJI A3 series flight controllers. Using dual antennas, its heading reference is more accurate than a normal
compass sensor, and it is able to withstand magnetic interference from metal structures.
Depending on the region of purchase, the D-RTK uses either GPS and BeiDou or GPS and GLONASS to
perform at the highest standards.
Overview
D-RTK Processor ×2
Antenna Bracket I ×1
DATALINK PRO Bracket ×1
4-pin CAN Cable ×1
Air System Power Cable I ×1
GNSS Antenna ×3
Antenna Bracket II ×2
Thumb Screw ×1
Micro USB Cable ×1
Air System Power Cable II ×1
Antenna Cable ×3
Base Board ×1
8-pin Cable ×1
Ground System Power Cable×1
Screw Others
M2.5 ×5
Velcro
M3.0 ×8 Double-sided
Tape
Cup-head Full
Hexagonal
Thread Screw
L-wrench
M3 & M3 Nut
