• Stop the engine and disconnect the spark plug cable:
a. If the machine steers away from the driving position.
b. If the auger housing or discharge chute is blocked and
must be cleaned.
c. Before beginning repairs or adjustments.
• Always make sure the rotating parts have stopped and all
the controls are disengaged before cleaning, repairing or
inspection.
• Before leaving the machine unattended, disengage all the
controls, put it into neutral gear, stop the engine and set
the stop switch in position "OFF".
• Never run the engine indoors except when taking it in and
out of its place of storage. In this case ensure the door to
the storage place is open. Exhaust fumes are toxic.
• Never drive across a slope. Move from the top down, and
from the bottom to the top. Be careful when changing
direction on a slope. Avoid steep slopes.
• Never operate the machine with insufficient protection or
without the safety devices in place.
• Existing safety devices must not be disconnected or
disengaged.
• Do not alter the engine's regulator setting and do not race
the engine. The possibility of personal injury increases
when the engine is run at high revs.
• Never use the snow thrower near enclosures, cars,
windowpanes, slopes etc. without properly setting the
discharge chute deflector.
• Always keep children away from areas to be cleared. Get
another adult to keep the children under supervision.
• Do not overload the machine by driving it too fast.
• Take care when reversing. Look behind you before and
during reversing to check for any obstacles.
• Never point the discharge chute towards bystanders. Do
not allow anyone to stand in front of the machine.
• Disengage the auger when the snow thrower is to be
transported or is not in use Do not drive too fast on
slippery surfaces when transporting.
• Only use accessories that are approved by the machine's
manufacturer.
• Never drive the snow thrower in bad visibility or without
satisfactory lighting.
• Always ensure you have a good balance and a tight grip
on the handle.
• Never use the snow thrower on a roof.
• Do not touch engine components because they are warm
during use. Risk of burn injuries.
2.4 MAINTENANCE AND STORAGE
• Tighten all nuts and screws so that the machine is in safe
working condition. Check the shear bolts regularly.
• Always use genuine spare parts. Non-genuine spare parts
can entail a risk of injury, even if they fit the machine.
• Never store the machine with petrol in the tank in
buildings where the fumes can come into contact with
open flames or sparks.
• Allow the engine to cool before putting the machine in
store.
• Before a long storage, check the instructions for
recommendations.
• Replace damaged warning and instruction stickers.
• Let the engine run a couple of minutes with the auger
connected after use. This prevents the auger from
freezing solid.
ENGLISH
Note: Instructions to the left and right sides start from the
driving position behind the snow thrower.
3.1 CONTENTS - OUTER PACKING
The packaging contains components to be installed on the
snow thrower according to the table below:
Detail
Snow thrower
Discharge chute
Handle
Screws and nuts for the above
Instructions
3.2 UNPACKING
1. Open the box carefully.
2. Take care of any documentation in the box, for example
these instructions.
3. Remove all loose items and mounting components from
the box.
4. Lift the snow thrower from the box.
5. Dispose of the box and packaging according to local reg-
ulations.
3.3 HANDLE (FIG. 2)
Raise the handle and tighten the two nuts (2:R).
3.4 SNOW DISCHARGE CHUTE (5:M)
1. Position the snow discharge chute (5:M) on the snow
thrower.
2. Install the three screws (5:U).
3. Tighten the screws.
The engine's silencer is fitted with a protective
plate (1:G). The engine may only be started when
this protective plate is installed and intact.
4.1 IGNITION KEY (1:A)
Used to stop the engine. The ignition key has two positions:
Left (vertical)-OFF The engine stops and cannot be
started. The ignition key can be removed in this po-
sition.
Right (horizontal)-ON- The engine can be started
and operated. The ignition key cannot be removed
in this position.
4.2 STARTER HANDLE (1:B)
Manual cord start with rewinding
4.3 CLUTCH LEVER – AUGER (1:D)
Engages the auger when the handle
is pressed towards the handlebar.
Original instructions for use
3 ASSEMBLY
Pos
M
-
-
-
4 CONTROLS
EN
Fig- No.
ure
1 1
1 1
1 1
- -
- 1
