8.6 Fixing the upper body

Fix the upper body (01) to the base (02) using the
fixing screws (03) equipped with gaskets (04). Make
sure the base seal is present and in good condition
(05).
Pay attention to the fixing. Tightening
torque: 4Nm.
01
05
Fig. 29
MNVCUPT3_1511_EN
Fig. 30
There is one anchoring position between
the base and upper body. Align side
projections to obtain the correct
02
positioning.
04
03
