GB Problem
If you're having a problem with the Force 28 Nitro engine:
Engine does not start
Engine does not draw
fuel
Engine has poor
performance
Engine overheats
Engine vibrates
excessively
Engine does not idle
down
EMS-Starter
28 CARSON Nitro Buggy CNB 204016
Cause
1. Failed glow plug
2. Glow Starter not charged and/or faulty
3. Idle mixture screw set too lean
4. Old or contaminated fuel
5. Engine flooded with too much fuel
6. Air leak in fuel system and/or engine
1. Air leak in fuel system and/or engine
2. High speed needle valve fully closed
3. Idle mixture screw set too lean
4. Fuel lines kinked
5. Defective fuel tank
1. Failed and/or wrong type glow plug
2. Old and/or wrong type fuel
3. High speed needle valve set too rich
4. Idle mixture set too lean
5. Idle mixture set too rich
6. Air leak in fuel system and/or engine
1. Engine running too lean
2. Body too restrictive
3. Wrong type of fuel used
4. Engine not fully broken in
Engine and/or engine mounts loose
1. Idle stop screw out of adjustment
2. Engine has developed an air leak
3. One or more carburretor 0-rings damaged
Does not work
Solution
Replace glow plug with new one
Fully charge glow starter and/or replace
Reset idle mixture to factory setting (p 17)
Replace with new fuel
Remove glow plug and expel fuel from cylinder
(p 17)
Replace fuel lines and/or tighten all engine bolts
Replace fuel lines and/or tighten all engine bolts
Reset high speed needle valve to factory setting
(p 17)
Reset idle mixture to factory setting (p 17)
Check and straighten fuel lines
Replace fuel tank
Replace with new recommended glow plug (p 7)
Replace with new recommended fuel (P4)
Reset high speed needle valve to leaner setting
(p 17)
Set idle mixture richer (p 17)
Set idle mixture leaner (p 17)
Replace fuel lines and/or tighten all engine bolts
Richen high speed needle valve (p 17)
Open larger vents in body to allow air to enter
and exit
Use fuel recommended only for R/C cars (p 6)
Allow engine further break-in time (p 19)
Tighten all engine and engine mounting bolts
Adjust idle stop screw to factory setting (p 17)
Check and tighten all engine screws
Replace carburretor 0-rings
Check the battery
