8. Parts list

No.
001 Main Frame
002 Front Stabilizer
003 Rear Stabilizer
004 Idle Wheel Bracket
005 Seat Post
006 Seat Sliding Tube
007 Handlebar Post
008 Handlebar
009 U Bracket
010 Washer Ø16xØ8x1.5
011 Eyebolt M8x85
012 End Cap For Front Stabilizer
013 End Cap For Rear Stabilizer
014 Big Curve Washer Ø8
015 Adjustable Leveler M8
016 Spring Ø6
017 Bolt M8x70
018 Seat Sliding Tube End Cap (□38)
019 Bolt M8x15
020 Bolt M8x20
021 Eyebolt M6x36
022 Idle Wheel Ø10xØ35
023 Screw ST2.9×12
024 Screw ST4.2×20
025 Screw ST4.2×25
026 Pan Head Phillips Self Drilling
Screw ST4.2x25
027 Nylon Nut M8
028 Nut M6
029 Hexagon Nut M10
No.
059 Seat Post Cover
060 Belt PJ360 J6
061 Seat Cushion DD-982AT
062 Computer
063 Extension Sensor Wire
(L=1000mm)
Description
Description
Qty No.
1 030 Cap Nut M8
1 031 Flywheel Ø230x40xØ32
1 032 Bearing Cup
1 033 Bearing 6000ZZ
1 034 Bearing Nut I 15/16"
1 035 Bearing Nut II 7/8"
1 036 Washer Ø24xØ40x3.0
1 037 Washer Ø23xØ34.5x2.5
2 038 Hexagon Nut 7/8"
6 039 Belt Pulley with Crank Ø240J6
1 040 Bolt M5X45
2 041 Big Curve Washer Ø5
2 042 Bolt M5X10
8 043 Handlebar Foam Grip Ø24xØ30x550
1 044 Left Pedal YH-30X
2 045 Right Pedal YH-30X
4 046 End Cap for Handlebar
2 047 Cover Cap
4 048 Round Knob M16
1 049 Hand Pulse Sensor with Wire
L=750mm
2 050 Sensor with Wire L=750mm
1 051 Left Chain Cover
2 052 Right Chain Cover
6 053 Seat Post Bushing
7 054 Tension Control Knob
4 055 Tension Cable L=1150mm
6 056 Clamp Cover
2 057 Spacer (Ø12x20x1.5)
2 058 Handlebar Post Cover
Qty No.
1 064 Handlebar T-Knob (M8x55)
1 065 Washer Ø12x Ø6x1.0
1 066 Bolt M6X10
1 067 Plug
49
Description
Description
EN
Qty
4
1
2
2
1
1
1
1
1
1
1
1
4
2
1
1
2
2
1
2
1
1
1
1
1
1
1
1
1
Qty
1
1
1
1
